Supporting Collateral
© 2025 Microchip Technology Inc. and its subsidiaries
DS50004037A - 1
Introducon
This document is designed to help system integrators follow a systematic debugging process. It aims to
eciently identify the problem's source and gather the necessary information to nd an suitable solution. The
information contained within the document can be used to root cause and resolve issues with the Microchip
KSZ8081MNX. In the event that a root cause or solution cannot be identied, this document can be used as a
guide to prepare the necessary information for submitting a Microchip support case request.
This document covers the following topics:
Problem Statement Questionnaire
Data Logging
Debug Flow for Problem Isolation
This document also includes the following supplemental information:
Low Level Management Techniques
PHY Link Registers and Testing
Additional resources which are recommended are:
•KSZ8081MNX
Datasheet
•KSZ8081/KSZ8091 Silicon Errata and Datasheet Clarication
•KSZ8081MNX Schematic Checklist
•KSZ8081MNX Evaluation Board
•KSZ8081MNX Design Package
•AN1120- Ethernet Theory of Operation
•PCB Design Guidelines for QFN and DQFN Packages
•Magnetics Selection Guide
•Ethernet Compliance Testing
•Capacitive Coupling Ethernet Transceivers without Using Transformers
•Microchip University - Ethernet Fundamentals
KSZ8081MNX Issue Triage Guide
