INSTALLATION INSTRUCTIONS FOR PART 99-5829CH
APPLICATIONS
METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
REV. 8/2/2013 INST99-5829CH
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
Table of Contents
• ISO DIN head unit provision with pocket
• DDIN head unit provision
• Painted Charcoal Grey
• A) Radio Trim panel • B) Radio Brackets • C) Pocket • D) (4) #8 x 3/8” Phillips screws for pocket
• E) (4) #8 x 3/8” Phillips screws for OE Display to Housing • F) (2) Ford Panel Clips
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • AX-ADBOX1 Interface
• AX-ADBOX2 Interface • AX-ADFD02 Harness
Antenna Adapter: • 40-EU10 Multi-App Antenna Adapter
• Panel removal tool • Phillips screwdriver
• Socket Wrench • Torx screwdrivers
TOOLS REQUIRED
Ford Edge 2011-up (With 4.3” screen, without Ford MyTouch)
99-5829CH
A
BCD
EF
Dash Disassembly
–Ford Edge 2011-up ..............................................2
Kit Assembly
–ISO DIN radio provision with pocket ......................3
–DDIN radio provision ............................................3
–Environmental controls & LCD color adjustment 4-5
