INSTALLATION INSTRUCTIONS FOR PART XSVI-9004-NAV

METRA. The World’s best kits.™metraonline.com1-800-221-0932

© COPYRIGHT 2004-2014 METRA ELECTRONICS CORPORATION

REV. 9/17/2014 INSTXSVI-9004-NAV

CAUTION: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE: Refer to the instructions included with the

aftermarket radio.

•Providesaccessory(12-volt10-amp)

•RetainsR.A.P.(retainedaccessorypower)

•ProvidesNAVoutputs(parkingbrake,reverse,andspeedsense)

•PrewiredASWC-1harness(ASWC-1soldseparately)

•Retainsbalanceandfade

•Micro“B”USBupdatable

FEATURES

•Cuttingtool•Crimpingtool•Tape•Connectors

(example:butt-connectors,bellcaps,etc.)

TOOLS REQUIRED

Audi CAN Interface

2002-2013

XSVI-9004-NAV

APPLICATIONS

•XSVI-9004interface•LD-AX-XSVI-AU1harness•LD-AX-XSVI-AU2harness

INTERFACE COMPONENTS

Connections to be made

–

FromtheLD-AX-XSVI-AU1harness...................2-3

–

FromtheLD-AX-XSVI-AU2harness...................4-5

Installing the XSVI-9004-NAV

–

FromtheLD-AX-XSVI-AU1harness......................3

–

FromtheLD-AX-XSVI-AU2harness......................5

Troubleshooting

–

FromtheLD-AX-XSVI-AU1harness......................3

–

FromtheLD-AX-XSVI-AU2harness......................5

Table of Contents

AUDI

Applications below use

LD-AX-XSVI-AU1:

A3*2006-2013

A4/RS4/S4with NAV2005-2008

A4/RS4/S42007-2008

A4/RS4/S4*2006

TT2008-2013

Applications below use

LD-AX-XSVI-AU2:

A3**2006-2007

A4/S4***2002-2006

A62004

allroad2004-2005

TT2002-2006

Note:

* Only for models with either a

Symphony Plus or NAV radio.

** With Concert radio (without NAV)

*** With Symphony radio

(without NAV)
