Pagina 1/2
Quick Start Guide
Model:
GMR-RB4
Description:
Add-On Relay Bank for GMR7V1
It is always a best practice to disconnect your negative battery terminal prior to any electronics
installations to avoid damaging the vehicle’s electrical system. Before you begin, read through
these instructions and check that all parts are present.
This installation may require special skills and tools to complete from a trained installation
technician. Please note that MB Quart cannot assume any responsibility for damage resulting
from incorrect installation.
No. Description
1 12v+ Battery Connector 8awg wire with 80amp fuse
2 12v- Battery Connector 8awg wire
3 CH1 Positive Output
4 CH1 Negative Output
5 CH2 Positive Output
6 CH2 Negative Output
7 CH3 Positive Output
8 CH3 Negative Output
9 CH4 Positive Output
10 CH4 Negative Output
11 CH1-4 Trigger Input from GMR7
12 (1) 20-Amp Fuse Per Channel with blown fuse indicator LED*
Features
1 2 3 4 5 6 7 8 9 10
11
12
*The LED will light up to indicate a blown fuse as long as a load is still connected to the circuit.
BATTERY
GMR7V1
LED WHIPS
L
LED
FUSE
Wiring Diagram
GMR-RB4 QSG Rev1
MB Quart products are designed and engineered in the USA by
www.maxxsonics.com
WARRANTY
Maxxsonics, LLC. warrants this product, to the original consumer purchaser, to be free from
defects in material and workmanship for a period of one (1) year from the date of purchase.
Maxxsonics, LLC. will, at it’s discretion, repair or replace defective products during the warranty
period. Components that prove to be defective in materials and workmanship under proper
installation and use must be returned to the original authorized Maxxsonics, LLC. retailer from
where it was purchased. A photocopy of the original receipt must accompany the product being
returned. The costs associated with removal, re-installation, and freight are not the responsibility of
Maxxsonics, LLC. This warranty is limited to defective parts and specically excludes any incidental
or consequential damages connected therewith. To view the full warranty, please visit the website.
