1

03/2025

P/N 0302184 Rev A

®

English

Humidity Sensor Switch120 V~ 50 / 60 HzMS-HS3Fan 3 A

Introduction

The humidity sensor switch controls exhaust and vent fans to remove moisture in the space when humidity levels exceed the threshold. The humidity sensor

switch is ideal for bathrooms as it can detect rapid increases in humidity from showers or baths to reduce mold and mildew. It will also detect gradual

increases in humidity in bathrooms as well as utility rooms, basements, and other spaces.

Important Notes

1. CAUTION: To reduce the risk of overheating and possible damage to other equipment, DO NOT use to control receptacles.

2. Install in accordance with all national and local electrical codes.

3. A neutral or ground connection is required for the product to function. When a neutral connection is available, remove the green sleeve and connect to the

neutral. If a neutral is not available, connect the green-sleeved wire to ground only in retrofit and replacement applications. If neither wire is present, consult

a licensed electrician.

4. For indoor / dry location use only. Operate between 32 °F and 104 °F (0 °C and 40 °C).

5. Clean with a soft damp cloth only. DO NOT use any chemical cleaners.

6. DO NOT exceed twenty (20) devices on a single branch circuit.

7. Device makes an audible click when turning on / off. This is normal functionality.

8. Do not use for ceiling paddle fans.

9. For supply connections use 18 AWG (1.0 mm

2

) or larger wires suitable for at least 167 °F (75 °C).

ON

OFF

WARNING: SHOCK HAZARD.

May result in serious injury or death. Turn off power at circuit breaker or fuse before installing.

1

Turn power OFF at the circuit breaker

2

Ensure a neutral or ground connection is present

Look for a bundle of white neutral wires coming out of the electrical box.

A.When a neutral is present, remove the green sleeve and connect the white wire to neutral from the electrical box. Connect the bare wire from the device to

the ground wire from the electrical box.

B.If no neutral is present, connect the bare and green-sleeved wire from the device to the ground wire from the electrical box (can only be used in retrofit and

replacement applications when neutral is not available).

C.If neither wire is present, consult an electrician. This device will not function if it is not connected to neutral or ground.

WARNING: ENTRAPMENT HAZARD.

To avoid the risk of entrapment, serious injury, or death, these controls must not be used to control equipment that is not visible from every control

location or that could create hazardous situations if operated accidentally or through malfunction (for example, motorized gates, garage doors,

industrial doors, microwave ovens, heating pads, fireplaces, space heaters, etc.). It is the installer’s responsibility to ensure that these controls are

connected only to suitable loads and equipment types and that such equipment is visible from every control location. Failure to do so could result in

serious injury or death.
