Lorex Corporation
10440 Little Patuxent Parkway, Ste, 300,
Columbia, MD 21044, United States
© 2024 Lorex Corporation
As our product is subject to continuous improvement, Lorex Technology & subsidiaries reserve the right to
modify product design, specications & prices without notice and without incurring any obligation. E&OE.
11202024-3
lorex.com
AJLD Series
PRODUCT SPECIFICATIONS
Product DescriptionJunction Box for Dome and Turret
Cameras
MaterialAluminium
FinishingPowder Spray
ColorWhite, Black
Operating Temperature-40 °F to 140 °F / -40 °C to 60 °C
Humidity<90% RH
Load-Bearing Weight6.61 lbs / 3 kg
IP RatingIP66
Product Weight1.2 lb / 0.54 kg
Product Dimensions
(W × D × H)
5.27 × 5.25 × 2.05” /
134 × 133.5 × 52 mm
Junction Box
MODEL INFORMATION
AJLD-1W26-95529-06233-4
AJLD-1B2
6-95529-06232-7
PACKAGE DIMENSIONS
PackageBrown Box
Package Weight1.52 lb / 0.69 kg
Package Dimensions
(W × D × H)
5.75 × 2.6 × 5.79” /
146 × 66 × 147 mm
Package Cube0.05 ft³ / 0.0014 m³
PACKAGE CONTENTS
• 1 Junction Box×
• 4 Mounting Screw×
• 4 Mounting Anchor×
• 4 Washer×
• 1 Allen Key×
• 3× Machine Screw
• 1× Cable Gland
• 1× Quick Start Guide QR Card
PRODUCT DIMENSIONS
3.86” / 98 mm
2.05” / 52 mm
5.25” / 133.5 mm
98” / 3.86 mm
9-M4
G3/4
ΦΦ3.86” / 98 mm
ΦΦ4.33” / 110 mm
4-0.Φ33” / 8.5 mmΦ1.89” / 48 mm
3.54” / 90 mm
G3/4×1.814-6g
ΦΦ3.31” / 84 mm
4-ΦΦ0.19” / 4.8 mm
1.30” / 33 mm
1.82” / 46.2 mm
0.6” / 15 mm
0.07” / 1.8 mm
0.63-0.Φ39” / 16 mmΦ
ΦΦ0.77” / 19.5 mm
ΦΦ1.44” / 36. 7 mm
