JP Shallow Well Jet Pump

OWNER'S MANUAL

English

EN

The convertible jet pump is ideal for the supply of fresh water

to rural homes, farms, and cabins. Manufactured for shallow

well installations down to depths of 25 feet. Featuring a cast

iron casing, heavy-duty dual-voltage motor, factory pre-set

30/50 pressure switch, and glass-filled thermoplastic impeller

and diffuser, this durable pump offers reliable service for shal-

low well applications.

This product is covered by a Limited Warranty for a period of 1 year from the date of original purchase by

the consumer. For complete warranty information, refer to www.LittleGiant.com

.

Specifications

SAFETY INSTRUCTIONS

This equipment should be installed and serviced by technically qualified personnel who are familiar with

the correct selection and use of appropriate tools, equipment, and procedures. Failure to comply with

national and local electrical and plumbing codes and within Little Giant recommendations may result in

electrical shock or fire hazard, unsatisfactory performance, or equipment failure.

Know the product’s application, limitations, and potential hazards. Read and follow instructions carefully to

avoid injury and property damage. Do not disassemble or repair unit unless described in this manual.

Refer to product data plate(s) for additional precautions, operating instructions, and specifications.

Failure to follow installation or operation procedures and all applicable codes may result in the following

hazards:

ModelVoltsAmpsMax PSIGHPPhaseSuctionDischarge

JP-050-C

115VAC12.4

64.21/2

Single1.25 inch FNPT1-inch Threaded FNPT

230VAC6.2

JP-075-C

115VAC14.8

653/4

230VAC7.4

JP-100-C

115VAC19.9

66.21

230VAC9.95

Risk of death, personal injury, or property damage due to explosion,

fire, or electric shock.

•Do not use in explosive atmospheres or hazardous locations as classified by the NEC, ANSI/NFPA70.

•Do not handle a pump or pump motor with wet hands or when standing on a wet or damp surface or in water

until the unit is unplugged or electrically disconnected.

•Do not use to pump flammable, combustible, or explosive fluids such as gasoline, fuel oil, kerosene, etc.

•When a pump is in its application, do not touch the motor, pipes, or water until the unit is unplugged or electri-

cally disconnected.

•If the power disconnect is out of sight, lock it in the open position and tag it to prevent unexpected application of

power.

•If the disconnect panel is not accessible in an emergency, contact the power company to stop service.
