9SC & 10SC SERIES
OWNER'S MANUAL
English
EN
This submersible sewage pump is for use in basins or
lift stations and is suitable for pumping effluent gray
water or wastewater with up to 2" (51 mm) spherical
semi-solids. Do not use the pump in applications
where any other debris (gravel, sand, floating debris,
etc.), abrasives, or corrosives are present.
The pump motor is equipped with an automatic reset-
ting thermal protector and may restart unexpectedly.
Protector tripping is an indication of motor overload-
ing/overheating, which can be caused by application
issues such as an obstructed pump impeller, switch
stuck in the ON position, pump running dry, pump air-
locked, pump short cycling, excessively high or low
voltage supply, or possibly a pump, motor, bearings, or seal that have reached the end of their useful life.
This product is covered by a Limited Warranty for a period of 3 years from the date of original purchase by
the consumer. For complete warranty information, refer to www.littlegiant.com
.
Specifications
ModelHPVoltsHz
Amps
Watts
Maximum Water
Temperature
FLAStart
9SC4/10
11560
8.0
18.5
870
140 °F
(60 °C)
10SC (2” Discharge)
1/2
11.01225
23050/605.5/5.513/13
991/1214
10SC (3” Discharge)
1004/1228
1156011.518.51270
Model
Gallons (Liters) per Minute, at HeightShut Off
5 ft (1.5 m)10 ft (3 m)15 ft (4.5 m)20 ft (6.1 m)Feet (Meters)PSI (Bar)
9SC100 (379)80 (303)60 (227)-20 (6.1)8.7 (0.6)
10SC (2” Discharge)120 (454)100 (379)80 (303)42 (159)25 (7.6)10.9 (0.7)
10SC (3” Discharge)130 (492)110 (416)85 (322)50 (189)25 (7.6)10.8 (0.7)
Model Switch TypeON LevelOFF Level
9SC-CIA-SFSIntegral Snap-Action Float10 - 13” (25 - 33 cm)5 - 8” (13 - 20 cm)
9SC-CIA-RF
Piggyback Mechanical Float16 - 19” (41 - 48 cm)9 - 11” (23 - 28 cm)
10SC-CIA-RF
10SC-CIA-SFSIntegral Snap-Action Float11 - 14” (28 - 36 cm)6 - 9” (15 - 23 cm)
