Rugged, temperature-enhanced 28-port Gigabit access switch
with cloud management for exclusive fiber-optic connectivity in
harsh industrial environments
For industrial companies, infrastructure providers, and operators of critical systems, the
LANCOM IGS-3128XF serves as a reliable distribution instance for internally networking
other switches within the network. With its robust metal housing, flexible fiber-optic
connectivity across all ports, and extended temperature tolerance, this cloud-ready
industrial switch is ideally suited for demanding environments such as manufacturing,
logistics, or energy supply. The 28-port Gigabit access switch features 24x 1G SFP ports
– – 4 of which can be used as combo ports (TP/SFP) as well as 4x 10G SFP+ ports for
uplinks and backbone connections. For flexible power supply options, the LANCOM
IGS-3128XF comes with an internal AC power unit and an additional connector for external
DC power sources. Its shallow housing depth allows for space-saving installation,
particularly in compact distribution cabinets. With layer 3 lite functionality and support
for the LANCOM Management Cloud (LMC), the LANCOM IGS-3128XF enables centralized
and automated management of both the device and the entire network.
→Industrial Gigabit access switch with fiber-optic support on all ports: 20x 1G SFP
ports, 4x combo ports (TP/SFP), and 4x 10G SFP+ ports
→AC and DC input for maximum flexibility in the choice of power supply
→Robust metal housing for reliability in harsh environments and demanding temperatures
(-20 °C to +55 °C)
→Basic layer-3 features such as static routing and DHCP server
→Security with configurable access control on all ports as per IEEE 802.1X and access
control lists
→Secure remote management through TACACS+, SSH, SSL, and SNMPv3
→Cloud-managed LAN for fast configuration and convenient management via the
LANCOM Management Cloud
→IPv6 and IPv4 support for modern enterprise networks
→Includes a serial configuration cable, and an IEC power cable, mounting brackets can
be unscrewed
→5-year replacement service for all components
LANCOM IGS-3128XF
lancom-systems.com
LANCOM Data sheet - Switches
High performance on 28 ports
The LANCOM IGS-3128XF is equipped with 20x 1G SFP ports, 4x combo ports (TP/SFP),
and 4x 10G SFP+ ports supporting transfer rates of up to 10 Gbps. The combo ports can
be used flexibly as either copper (RJ45) or fiber-optic ports (SFP). With a data throughput
of 128 Gbps on the backplane, it also offers full performance even under heavy load.
This makes the industrial access switch the ideal central distribution instance in the
network for connecting additional switches in modern network infrastructures.
Designed for industrial applications
Designed for use in severe frost or extreme heat (-20 °C to +55 °C), the LANCOM
IGS-3128XF is optimally tailored to the requirements of the industrial and manufacturing
sectors. Its metal housing provides enhanced resistance to bumps and vibration, while
AC and DC inputs offer maximum flexibility in power supply options. The shallow housing
depth of just 211 mm saves valuable space and allows for flexible installation even in–
small network cabinets or confined environments. Compared to many standard switches
with a depth of 300 400 mm, this design leaves ample room for effective cable–
management and optimal air circulation.
Cloud-managed LAN with port templates and Secure Terminal Access
With the LANCOM Management Cloud (LMC) and Cloud-managed LAN, the LANCOM
IGS-3128XF offers quick and easy network integration as well as automatic provision of
the configuration across locations with the a click of a mouse. Time-consuming individual
device and switch port configurations are now a matter of the past. The targeted switch
rollout via the LMC enables automatic VLAN assignment to switch ports including practical
switch port profiles and therefore zero-touch assignment to the devices. Secure“ ”
Terminal Access provides access to the command line of the LANCOM switch ("CLI
tunneling") directly from the LANCOM Management Cloud encrypted and without–
leaving the cloud interface. Secure Terminal Access provides expert functions as well
as extensive diagnostic and troubleshooting commands for the devices. Some highlights
include: trace and ping commands for quick troubleshooting, access to low-level“ ” “ ”
configuration parameters and detailed statistics of the LCOS SX operating system as
well as secure remote access to third-party devices in the local network via the integrated
SSH client.
Interference-free high-speed transmissions over distances of several kilometers
The LANCOM IGS-3128XF supports fiber-optic connectivity on all 28 ports, enabling
reliable high-speed data transmission even across long distances. Link aggregation
(LACP) allows multiple ports to be combined into a single logical channel, achieving a
total transmission rate of up to 40 Gbps. As a result, this industrial access switch
significantly boosts network performance and is ideal for organizations with extensive
or distributed infrastructures. Another advantage: fiber-optics not only enhance
installation flexibility but also effectively protect the network from electromagnetic
interference for example, when cables are laid parallel to power or machinery lines.–
LANCOM IGS-3128XF
lancom-systems.com
2 LANCOM Data sheet - Switches
High reliability through redundant power supply
As a central distribution point for stable internal networking, the continuous availability
of the LANCOM IGS-3128XF is essential. In addition to the integrated 100 240 V AC–
power supply, the industrial access switch also supports a 24 54 V DC power supply–
via an optional external power adapter (connection block), ensuring high operational
reliability. If one power source fails, the other takes over guaranteeing uninterrupted–
operation, even in critical infrastructure environments.
Configurable access control & secure remote management
The LANCOM IGS-3128XF stops rogue clients from gaining unauthorized access to the
network. This is ensured by secured access control on all ports as per IEEE 802.1X
(port-based, single, multi, and MAC-based) or by ACLs (access control lists). Thanks to
secure communication protocols such as SSH, SSL, and SNMPv3, professional remote
management of the network is possible. The switch also supports the TACACS+ protocol
for authentication, authorization, and accounting. This optimized solution promises
maximum security for multi-site network management and monitoring.
DHCP server functionality
As a DHCP server, the switch can independently and automatically assign IP addresses
to clients. The LANCOM IGS-3128XF supports this basic layer-3 function and thus takes
over the IP management of the connected network.
Static routing for efficient networks
The LANCOM IGS-3128XF supports the basic layer-3 function of static routing, shifting
certain routing tasks from the router to the switch. The predefinition of network routes
through one or more network segments enables faster data exchange, especially in the
case of high internal data traffic, and reduces the load on the router. Freed-up router
capacity is then additionally available for handling external data traffic. This increases
the efficiency of the entire network.
IPv6 and IPv4 support
Thanks to its dual-stack implementation, the LANCOM IGS-3128XF can be used in pure
IPv4, pure IPv6, or mixed networks. Numerous applications such as SSL, SSH, Telnet,
or TFTP can thus also be run over IPv6 networks. IPv6 features such as stateless
autoconfiguration, neighbor device discovery, and MLD snooping round out the IPv6
features.
LANCOM IGS-3128XF
lancom-systems.com
3 LANCOM Data sheet - Switches
