1 / 4

yraropmetnoCyraropmetnoClanoitidarTlanoitidarT

If drilling a new door, use the supplied template and the complete

door drilling instructions available at www.kwikset.com/doorprep

35 – 51 mm

1"

25 mm

1

2

Prepare the door and check dimensions

Install the latch and strike

60 or 70 mm

backset

in the door edge is 1" (25 mm).

Remove your existing deadbolt

and strike from your door.

CDEF

B

Keys

Exterior Assembly

Adapter

Ring

Batteries

Mounting

Plate

Parts in the Box

For Latch / Strike

Interior Assembly

SmartKey

Tool

or

54 mm

38 mm

Note: Additional door preparation

may be required for doors with

deadbolt drilling instructions at

www.kwikset.com/doorprep

A

Make sure your door is compatible. If you have a standard deadbolt mounted

separately from the handle below it, your door is compatible.

Mortise

Lock

Not CompatibleNot Compatible

Rim

Lock

CompatibleNot Compatible

Integrated

Interior

actual size

Strikes

03809

69316

kcoL roF

03809

46780

actual size

For Latch /

Strike Bag

(2x)(2x)

(2x)(2x)

68611

Installation and User Guide

ENGLISH

Required tools

Ruler

Phillips head screwdriver

54471-001

Rev 01

Kwikset

Technical Support

www.kwikset.com

1-866-863-6584

46780

48654

Latch A

Latch B

“B” is not included. If needed,

please contact Kwikset to order

a drive-in latch for your lock.

A

03809*

(2x)

(For Latch/

Strike Bag)

A

A

B

B

B

A

B

AB

C

D

Is the door edge chiseled?

Is the D-shaped hole centered in the door hole?

Which latch are you installing?Hold the latch in front of the door hole, with the latch

face flush against the door edge.

YES

YES

NO

NO

Use latch “A”. If the

latch bolt is not already

extended, extend the

latch bolt as shown.

No adjustment is required.

Proceed to next step.

D-shaped hole

Rotate latch face as

shown to extend latch.

UP is

on top.

UP is

on top.

wood

block

Use latch “B." If the

latch bolt is not already

extended, extend the

latch bolt as shown.

Latch “A”Latch “B”

E

Install the strike on the door frame.

Make sure the hole in the door frame is drilled a

minimum of 1" (25 mm) deep.

or

chiseled

not

chiseled

or

or

door frame

46780

(4x)

(For Latch/Strike Bag)

Longer screws install

closest to the door jamb.

or

or

*Use longer

screws if holes

are worn out.

You will have two

extra screws.

Note: there will be extra screws and a strike.

D-shaped hole

Z-Wave Plus

®
