INSTALLATION SHEET
FM43313
LED Flush Mount
START FROM HERE
Please Note:
•All Kuzco LED fixture comes with pre-wired LED module(s).
• Unless instructed to do so, please do not touch any part of the LED module(s) as any
unnecessary contact with the module could cause permanent damage.
• For dimming, an ELV (Electronic Low Voltage) type of dimmer is required.
•
Make sure power is completely off at the fuse box.
•
Have your fixture installed by a qualified licensed electrician
•
Prepare everything in a clear area.
•
Wear gloves at all times during this installation.
•
Read instructions carefully before you start assembly.
•
Keep this instruction sheet for future reference.
Technical Support: 1-855-855-8926
.
19054 28th Avenue Surrey, BC Canada V3Z 6M3
T: 604 538 7162 TF: 1-855 85 KUZCO F: 604 538 7196
W: kuzcolighting.com
1a.
1b.
1c.
1d.
1e.
1f.
2a.
1g.
3a.
1. Remove fixture from its original package
2. Attach crossbar to electrical junction box (1c)(1a)
using screws provided in hardware package(1e)
3. Make proper electrical connections (black to hot “L”,
white to neutral “N”, ground to “GND”) with wire nuts
(1b) provided in hardware package
4. Install Pan-Head Crossbar Mounting Screws (1d)
halfway into threaded holes on crossbar . Align (1c)
keyholes on backplate and module to Pan-Head (2a)
Crossbar Mounting Screws heads, insert and turn, (1d)
and then secure with screw driver.
5. Secure backplate to ceiling with additional screws (2a)
(1g) and anchors if necessary(1f)
6. Twist shade onto backplate to secure(3a)(2a)
20210329
