Pagina 1/27

P/N: 2900-301167 Rev 3 www.kramerAV.com

USER MANUAL

MODEL:

KDS-8, KDS- 8F

SDVoE Streaming Transceivers

Kramer Electronics Ltd.

KDS-8 – Contents

Contents

Introduction 1

Getting Started 1

Overview 2

Defining KDS-8 SDVoE Streaming Transceiver 4

Mounting KDS-8 8

Connecting KDS-8 9

Connecting KDS-8F 10

Operating KDS-8 12

Changing Encoder/Decoder Mode – Front Panel 12

Configuring Settings – OSD 13

Technical Specifications 22

Kramer Electronics Ltd.

KDS-8 – Introduction

Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world

of unique, creative, and affordable solutions to the vast range of problems that confront the

video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we

have redesigned and upgraded most of our line, making the best even better!

Getting Started

We recommend that you:

• Unpack the equipment carefully and save the original box and packaging materials for

possible future shipment.

• Review the contents of this user manual.

Go to www.kramerav.com/downloads/KDS-8 to check for up-to-date user manuals,

application programs, and to check if firmware upgrades are available (where appropriate).

Achieving Best Performance

• Use only good quality connection cables (we recommend Kramer high-performance,

high-resolution cables) to avoid interference, deterioration in signal quality due to poor

matching, and elevated noise levels (often associated with low quality cables).

• Do not secure the cables in tight bundles or roll the slack into tight coils.

• Avoid interference from neighboring electrical appliances that may adversely influence

signal quality.

• Position your Kramer KDS-8 away from moisture, excessive sunlight and dust.

This equipment is to be used only inside a building. It may only be connected to other

equipment that is installed inside a building.

Safety Instructions

Caution:

• This equipment is to be used only inside a building. It may only be connected to other

equipment that is installed inside a building.

• For products with relay terminals and GPI\O ports, please refer to the permitted rating

for an external connection, located next to the terminal or in the User Manual.

• There are no operator serviceable parts inside the unit.

Warning:

• Use only the power cord that is supplied with the unit.

• To ensure continuous risk protection, replace fuses only according to the rating

specified on the product label which located on the bottom of the unit.

Product specificaties

Merk:	Kramer
Categorie:	AV extender
Model:	KDS-8
Kleur van het product:	Zwart
Gewicht:	500 g
Breedte:	231 mm
Diepte:	116 mm
Hoogte:	25 mm
Gewicht verpakking:	1200 g
Breedte verpakking:	351 mm
Diepte verpakking:	212 mm
Hoogte verpakking:	72 mm
LED-indicatoren:	Power, Status
Connectiviteitstechnologie:	Bedraad
Ethernet LAN:	Ja
Ondersteunde video-modi:	2160p
Maximum resolutie:	3840 x 2160 Pixels
Audiosysteem:	Multikanaal
HDCP:	Ja
Aansluiting voor netstroomadapter:	Ja
Ondersteunde grafische resoluties:	3840 x 2160
Remote (IR) ingang:	1
Kleurdiepte:	10 Bit
Temperatuur bij opslag:	-20 - 70 °C
Audio-uitgangskanalen:	7.1 kanalen
Output current:	3 A
Ethernet interface type:	10 Gigabit Ethernet
Remote (IR) uitgang:	1
Soort aansluiting:	RJ-45
Maximale overdrachtssnelheid van gegevens:	10000 Mbit/s
HDMI in:	1
RS-232 ingangspoorten:	1
RJ-45 uitgang ports:	2
HDCP versie:	2.2
IR-doorvoer:	Ja
Bandbreedte:	10 Gbit/s
Aantal HDMI-uitgangen:	1
Operating voltage:	12 V
Maximaal bereik:	100 m
Bedrijfstemperatuur (T-T):	0 - 45 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
3,5 mm-uitgang:	Ja
SFP transceiver type:	Koper
HDCP-passthrough:	Ja
RS-232-passthrough:	Ja
