INSTRUCTIONS PERTAINING TO A RISK OF FIRE,OR INJURY TO

PERSONS

IMPORTANT SAFETY INSTRUCTIONS

Lighted lamp is HOT!

WARNING — To reduce the risk of FIRE OR INJURY TO PERSONS.

1) Turn off / unplug and allow to cool before replacing lamp.

2) Lamp gets HOT quickly! Contact only switch / plug when turning on.

3) Do not touch hot lens or cowl.

4) Do not remain in light if skin feels warm. (Light is intense, it may cause

“sunburn”.)

5) Do not look directly at lighted lamp.

6) Keep lamp away from materials that may burn.

7)Useonlywithwattageandlampmarkedonxture.

8) Do not touch the inner glass envelope of the lamp at any time. Use a soft

cloth. Oil from skin may damage lamp.

9)Donotoperatethexturewithadamagedormissinglens.

SAFETY INSTRUCTIONS

READ THIS FIRST

KEEP THESE INSTRUCTIONS

This xture is intended for installation in accordance with the National

Electric Code (NEC) and Local code specications. Failure to adhere

to these codes and instructions may result in serious injury and/or

property damage and will void the warranty.

1) WARNING: Thisxtureisnottobeinstalledwithin10feet(3M)ofapool,

spa or fountain.

2)Thisxtureistobeusedonlywithapowerunit(transformer)rateda

maximumof300W(25AMPS)15volts.

3)AccordingtotherequirementsoftheNationalElectricCode(NEC),

direct burial rated wire is to be buried a minimum of 6” [152mm]

beneath the surface of the ground.

NOTE: If additional Direct Burial wire is needed, contact your local Kichler

landscape distributor.

•8GAwirecanbepurchasedinlengthof250’(76M),15503-BK.

•10GAwirecanbepurchasedinlengthof250’(76M),15504-BK.

•12GAwirecanbepurchasedinlengthsof100’(30M),15501-BK;

250’(76M),15502-BK;500’(152M),15505-BK;and1000’

(304M),15506-BK.

4)Fixtureshallnotuseatungstenhalogenlampunlessthextureis

marked for use with such lamps.

5)Wiringconnectionsmustbemadewithapproved/listedwireconnection

device(s)suitablefortheapplication.Donotexceedmanufacturers’

wiringcombinationspecicationsforsizeandquantityofconductors.

CAUTION

WHEN INSTALLING KICHLER LANDSCAPE LIGHTING (LINE VOLTAGE OR LOW VOLTAGE),

CARE SHOULD BE TAKEN TO KEEP CLEAR OF POTENTIALLY COMBUSTIBLE MATERIALS.

WHEN MAINTAINING THE FIXTURES, BE SURE TO REMOVE LEAVES, PINE NEEDLES,

GRASS CLIPPINGS, MULCH, OR ANY DEBRIS THAT HAS ACCUMULATED ON THE LIGHT

BULB, LENS, OR BODY OF THE FIXTURE.

ASSEMBLY AND INSTALLATION

1)Determinedesiredlocationformountingxture.

2)Atdesiredlocation,hammerstake(A)intoground.Toavoiddamageto

stake, place a board on top of stake while hammering. If ground is hard

andstakeisdifculttoinstall,makeacrosscutingroundusingaat

shovel.

3)Clearawayareaingroundatwirewayslot(B)intopofstake(A).

4) Install lamp (C) in to socket (H). NOTE: Use caution when installing.

Holdlampbyouterhousing.DONOTtouchglassenvelopeinside.If

this happens, clean lamp with denatured alcohol and a lint free cloth.

5)Insertsocket(H)withlampintohousing(G).

6)Setglasslens(D)ontohousing(G).

7)Assemblecowl(E)tohousing(G).Secureinplaceusingeitherthe

provided thumb screw (F).

8)Lay12Vcableintowirewayslot(B)andscrewxtureintostake(A).

Whenatdesireddirectionrunlocknut(K)downagainststake(A).

9)Adjustangleofaccentlightbylooseningscrew(J).

10)TURNOFFPOWER.

11) Makewireconnectionsdirectlytoalowvoltagetransformerorconnect

to a low voltage power supply cable using the connectors supplied.

Date Issued: 1/27/12IS-15374-US

E

F

D

K

H

B

A

G

C

J

For warranty information please visit: http://www.landscapelighting.com/portal/warranty_page
