Keenetic Orbiter Pro KN-2810 Handleiding

Bekijk gratis de handleiding van Keenetic Orbiter Pro KN-2810 (2 pagina’s), behorend tot de categorie Access point. Deze gids werd als nuttig beoordeeld door 24 mensen en kreeg gemiddeld 4.3 sterren uit 6 reviews. Heb je een vraag over Keenetic Orbiter Pro KN-2810 of wil je andere gebruikers van dit product iets vragen? Stel een vraag

3

10:00

Mesh Wi-Fi

System

Acquire

4

5

10:00

Welcome to

Your Keenetic

Next

3

4

6

A

B

2

1

2

1

KEENETIC

ORBITER Ð

Quick Start Guide

AC1300 Mesh Wi-Fi 5 Gigabit Router/Extender with

2-Port Gigabit Smart Switch and Power over Ethernet

Model: KN-2810

Creating a New or Extending

an Existing Network

Keenetic routers deliver reliable, continuous, and secure

Wi-Fi throughout your home or business location. Starting with one

main Keenetic router, as your demands increase you can add more

Keenetic devices to act as Wi-Fi extenders, to create a centrally-

managed multi-node Mesh Wi-Fi System.

If you are creating a new network and this Keenetic Orbiter Pro

(hereinafter ‘Keenetic device’) is going to be your Main Router, put the

switch in position A H.

If you are extending an existing network and this Keenetic device

is to act as a Wi-Fi extender, put the switch in position I B.

A H — Connecting Your Keenetic Orbiter Pro

to the Internet

1. Set the physical Operating Mode Switch located on the back panel to position

АH — Router Mode.

2. Position your Keenetic device within cable length of a power outlet. Place your

Keenetic device in an open area for better wireless coverage. Connect your

Keenetic device to a power source. Check that the Status LED is on and solid

orange or green.

3. Сonnect a mobile device to your Keenetic router via Wi-Fi. The default Wi-Fi name

(SSID) and the Wi-Fi password are printed on your Keenetic device’s back label

along with a QR code that will automatically connect your mobile device to the

Keenetic router’s Wi-Fi when scanned. Alternatively, сonnect a computer to the

gray port marked 1 on your Keenetic device using the included Ethernet cable.

4. Once connected, an Initial Setup Wizard window will appear on your

mobile device / computer. If the Wizard does not appear, using a browser

go to my.keenetic.net and follow the setup instructions.

Note: If the Initial Setup Wizard still doesn’t appear, please refer to the

Frequently Asked Questions section below.

I B — Extending Your Existing Network Coverage

1. On the Keenetic device you wish to be a Mesh Wi-Fi Extender, set the Operating

Mode Switch located on the back panel to position I B — Extender Mode.

2. Connect your Keenetic device to a power source. Check that the Status LED

is on and solid orange or green.

3. Make sure your Keenetic Main Router is active and has an Internet connection.

Connect the 'Extender' Keenetic device to your Keenetic Main Router using

an Ethernet cable (as supplied). Alternatively you can connect Keenetic devices

wirelessly by placing them near to each other and simultaneously pressing the

Wi-Fi Control ButtonsD on both devices. Check that the Status LED on the

'Extender' is illuminated green.

4. Сonnect a mobile device / computer to your Keenetic Main Router network.

5. Launch a web browser and go to my.keenetic.net and log in to the Main Router

or launch the Keenetic Mobile Application. Then choose the Wi-Fi System section

and click Acquire to add an extender candidate to your Wi-Fi System. Wait for the

process to complete.

6. Disconnect the acquired Extender from the Main Router and place the Extender

where you want to expand your Wi-Fi network in your home. A Keenetic Mesh

Wi-Fi System supports both wireless and wired connections between the Main

Router and Extenders. To maximize your network performance, use wired

connections where possible. The Status LED on the Extender will illuminate

green when it has connected successfully to your network.

For technical support and other information, please visit

help.keenetic.com
