WARNING
FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and
qualified in pool equipment by the jurisdiction in which the product will be installed where such state or
local requirements exist. The maintainer must be a professional with sufficient experience in pool equipment
installation and maintenance so that all of the instructions in this manual can be followed exactly. Before
installing this product, read and follow all warning notices and instructions that accompany this product.
Failure to follow warning notices and instructions may result in property damage, personal injury, or death.
Improper installation and/or operation may void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which can
cause serious injury, property damage, or death.
ATTENTION INSTALLER - This manual contains important information about the installation,
operation and safe use of this product. This information should be given to the owner/
operator of this equipment.
INSTALLATION AND
OPERATION MANUAL
JCP Series High Performance
Commercial Pumps
JCP05-1CT-S
JCP07-1BD-S
JCP05-3AT-S
JCP07-3AT-S
JCP10-3AT-S
JCP15-3AT-S
JCP05-1CT-N
JCP07-1BD-N
JCP05-3AT-N
JCP07-3AT-N
JCP10-3AT-N
JCP15-3AT-N
H0679300_REV C
ENGLISH | FRANÇAIS | ESPAÑOL
Page 2
Jandy
®
JCP Series High Performance Commercial Pumps
|
Installation & Operation Manual
ENGLISH
Table of Contents
EQUIPMENT INFORMATION RECORD
DATE OF INSTALLATION
INSTALLER INFORMATION
INITIAL PRESSURE GAUGE READING (WITH CLEAR FILTER)
PUMP MODEL
HORSEPOWER
NOTES:
Section 1. Important Safety Instructions ....... 3
1.1 Safety Instructions .............................................. 3
1.2 Pool Pump Suction Entrapment Prevention
Guidelines .......................................................... 5
Section 2. General Description ....................... 6
2.1 JCP Series Pump Operations............................. 6
Section 3. Mechanical and Electrical
Installation and Pressure
Testing ............................................. 7
3.1 Pump Handling ................................................... 7
3.2 Pump Location ................................................... 7
3.3 Mechanical Installation ....................................... 8
3.4 Electrical Installation ........................................... 8
3.5 Strainer Pot Service ......................................... 10
3.6 Pressure Testing, Strainer Pot ........................... 11
Section 4. Jandy JCP Pump Operation ........ 13
4.1 Priming ............................................................. 13
Section 5. Maintenance and Storage ............ 14
5.1 Maintenance ..................................................... 14
5.2 Storage ............................................................. 14
Section 6. Servicing ....................................... 15
6.1 Required Tools.................................................. 15
6.2 Replacement Parts ........................................... 15
6.3 Alternate Parts .................................................. 15
6.4 Pump Disassembly ........................................... 15
6.5 Pump Assembly ................................................ 17
Section 7. Troubleshooting and Repair ........ 18
Section 8. Replacement Parts List ................ 21
8.1 JCP R-Kit List ................................................... 24
Section 9. Product Dimensions ..................... 28
Section 10. Product Specications ................. 30
10.1 Specications ................................................... 30
Section 11. Technical Data .............................. 31
