Pagina 1/60
Installation and Operation Manual
Manuel d’installation et d’utilisation
Manual de instalación y operación
Jandy X Series
™
AOP System
JAOPX500
WARNING
FOR YOUR SAFETY – This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed
where such state or local requirements exist. The maintainer must be a professional with sufficient experience in pool equipment installation and maintenance so that all of the instructions
in this manual can be followed exactly. Before installing this product, read and follow all warning notices and instructions that accompany this product. Failure to follow warning notices
and instructions may result in property damage, personal injury, or death. Improper installation and/or operation may void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which may cause serious injury, property damage, or death.
ATTENTION INSTALLER – This manual contains important information about the installation, operation and safe use of this product. This information should be given
to the owner/operator of this equipment.
Page 2
ENGLISH Jandy
®
X Series
™
AOP System | Installation & Operation Manual
Table of Contents
EQUIPMENT INFORMATION RECORD
DATE OF INSTALLATION _______________________________________________________________________________
INSTALLER INFORMATION _____________________________________________________________________________
NOTES _______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
Section 1. Important Safety Instructions ......... 3
Section 2. General Information ......................... 4
2.1 Description .....................................................4
2.2 Specifications .................................................4
Section 3. Installation ....................................... 5
3.1 Tools ............................................................... 5
3.2 Pool Preparation.............................................5
3.3 Location .........................................................5
3.4 Mounting ........................................................5
3.5 Plumbing ........................................................5
3.6 Electrical .........................................................7
Section 4. Operation .......................................... 8
4.1 Initial System Start-Up ...................................8
4.2 Normal Operation ...........................................8
4.3 System Shut-Down ........................................8
4.4 Winterizing ......................................................8
4.5 Water Chemistry .............................................8
Section 5. Maintenance & Service ................... 9
5.1 System Electromechanical Overview ............. 9
5.2 System Maintenance ......................................9
5.3 Standard Replacement Parts List ................11
5.4 Ozone System Maintenance ........................11
5.5 UV Reactor Service and Maintenance .........12
Section 6. Troubleshooting ............................. 16
Section 7. Appendices ..................................... 17
7.1 Appendix A: Jandy AOP X Series
Installation - System Plumbing ....................17
7.2 Appendix B: Pressure Drop Curve ...............18
7.3 Appendix C: In-Place Quartz Tube
Cleaning .......................................................18
