Pagina 1/24
H0514200 REVD
OWNER’S MANUAL
FOR YOUR SAFETY - This product must be installed and serviced by
a contractor who is licensed and qualified in pool equipment by the
jurisdiction in which the product will be installed, where such state or local
requirements exist. In the event no such state or local requirement exists,
the maintainer must be a professional with sufficient experience in pool
equipment installation and maintenance, so that all of the instructions in
this manual can be followed exactly. Before installing this product, read and
follow all warning notices and instructions that accompany this product.
Failure to follow warning notices and instructions may result in property
damage, personal injury, or death. Improper installation and/or operation
will void the warranty.
Improper installation and/or operation can create unwanted electrical hazard
which can cause serious injury, property damage, or death.
WARNING
Ozone Corona Discharge
CD40, CD70, CD100
Page 2
Jandy
®
Pro Series Ozone Generator
Section 1. Important Safety Instructions ....... 3
Section 2. Installation Requirements ............. 5
2.1 Parts You Need .............................................................5
2.2 Tools Required ..............................................................5
2.3 Power Requirements .....................................................6
2.4 Installation Location Requirements ...............................6
Section 3. Installation......................................... 6
Step 1. Mount the Generator .................................................. 6
Step 2. Connect Electrical Wiring ........................................... 8
Step 3. Plumb the Injector Manifold......................................10
Step 4. Install a Water Check Valve (if applicable) ............... 15
Step 5. Perform a System Pressure Test (if applicable) .......15
Step 6. Perform the Ozone Flow Test ...................................16
Section 4. Ozone Generator Operation .......... 18
4.1 Pool Preparation Before Startup....................................18
4.2 Water Chemistry ............................................................ 18
4.3 System Startup and Operation .......................................19
4.4 System Shut-Down and Winterizing ............................... 19
Section 5. Scheduled Maintenance................. 20
5.1 Check Power Supply to the Generator .......................... 20
5.2 Replace Ozone Modules ..............................................21
5.3 Verify Ozone Flow ........................................................21
5.4 Replace the Ozone Tube ...............................................21
Section 6. Troubleshooting ............................. 22
Section 7. Technical Support .......................... 24
Section 8. Replacement Parts ......................... 24
Table of Contents
