Pagina 1/4

Main Breaker

2-Pole, 30 A circuit

breaker shown

A=Black (Line)

B=Black (Line)

C=Ground (Green)

Type 2 Installation

Type 1 installation:

A typical installation of a type 1 SPD will be connected between the

secondary of the service transformer and the line side of the service

panel. This installation is intended to be installed overcurrent without

protection to the SPD.

1. Determining location:

• Ensure conductor lengths are as short and straight as

possible for best performance. Do not coil excess wire. The

SPD functions best if all bends in wires are rounded, ideally

to a 4” radius. Hard 90 degree bend will reduce efﬁciency.

Cut all leads to the correct length. Do not coil excess leads.

• Install appropriate weatherproof ﬁttings if the unit is to be

mounted outside.

2. Ensure all mounting and connections are correct and secure.

Once energized the green indicator LED will be ON and visible

through the cover of the SPD.

Type 2 installation:

A typical installation of a type 2 SPD will be connected to the load side

of the service panel and is intended to be installed overcurrent with

protection to the SPD.

1. Determining location:

• Ensure conductor lengths are as short and straight as

possible for best performance. Do not coil excess wire. The

SPD functions best if all bends in wires are rounded, ideally

to a 4” radius. Hard 90 degree bend will reduce efﬁciency.

Cut all leads to the correct length. Do not coil excess leads.

• Install appropriate weatherproof ﬁttings if the unit is to be

mounted outside.

2. Connect the green wire from the SPD to the ground bus bar in

the panel as shown.

3. Connect the two black wires to a circuit breaker as shown.

4. Ensure all mounting and electrical connections are correct and

securely fastened. Once energized the green indicator LED will

be ON and visible through the cover of the SPD.

AC Disconnect Installation

1. To be installed with over current protection up to 60 A.

Maintenance:

• AC Voltage SPD:

• Periodically check SPD to ensure green indicator LED is ON.

If green LED is OFF and the red LED is ON, protection has

diminished and the SPD should be replaced immediately.

INSTALLATION INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS • SAVE THESE INSTRUCTIONS

Model AG3000G

Type 1 or Type 2 Surge Protection Device (SPD)

• Disconnect power at the circuit breaker(s) or disconnect switch(es) before installing or servicing.

• Intended for indoor or outdoor use.

• Installation and/or wiring must be in accordance with national and local electrical code(s).

• Installation and service to be performed by a qualied licensed technician or electrician.

• Suitable for use on a circuit capable of delivering not more than 20,000 rms symmetrical amperes.

• This unit contains no serviceable parts.

WARNING

Risk of Fire or Electric Shock

NOTICE

NOTICENOTICE

• Thoroughly read instructions before installing SPD Unit.

• This product does not protect against lightning strikes.

• If the unit is mounted outdoors, the threaded nipple must be mounted horizontally into a suitable enclosure.

• L’installation et/ou le câblage doivent être conformes aux exigences du code de l’électricité local en vigueur et/ou du Code canadien de l’électricité.

• L’installation et l’entretien doivent être effectués par un technicien ou électricien qualié.

• Convient à un circuit capable de fournir PAS plus de 20 000 A efcaces symétriques.

• Cet appareil ne contient aucune pièce réparable.

AVERTISSEMENT

Risque d’incendie ou de choc électrique

Typical 240 VAC Application

Black

Green

Black

AC Disconnect

Line

LoadLoad

Line

GroundLine Line

AG3000G

How do I know my AG3000G is protecting my HVAC equipment?

A green LED indicator will illuminate when the AG3000G is operating normally and protecting your equipment. If the green indicator light is OFF

and the red LED is ON, the AG3000G will need to be replaced. You can order a new unit and have it installed by your local service installer. It is

the owner’s responsibility to check the LED status indicator of the AG3000G.

Understanding the AG3000G Limited Warranties

3-Year Limited Product Warranty

The AG3000G will be free from defects in material and workmanship for 3 years from date of purchase or 39 months from date of manufacture.

$7,500.00 Connected Equipment Warranty

If your connected equipment becomes damaged while using the AG3000G, please follow the claim process below:

1) Process an insurance claim with your homeowner’s insurance policy.

2) Send the AG3000G back to lntermatic for evaluation and testing to:

Intermatic Warranty Coordinator, 1950 Innovation Way, Suite 300, Libertyville, IL 60048

3) Upon receipt of the damaged AG3000G, lntermatic will investigate whether the AG3000G had a defect in material or workmanship that

led to the damage to your equipment. If the ﬁndings determine there was a defect in material or workmanship, lntermatic will cover any

costs beyond your homeowner’s coverage up to $7,500.00.

**Please sign below to acknowledge that you understand the limited warranties associated with the AG3000G and the responsibility of checking

the green indicator light to ensure protection of your HVAC equipment.

Homeowner’s Signature Service Installer Signature

Date of Installation Suggested Replacement Date

KEEP FOR YOUR RECORDS - THIS DOES NOT NEED TO BE MAILED TO INTERMATIC

THREE YEAR LIMITED PRODUCT and

CONNECTED EQUIPMENT WARRANTY for

INTERMATIC SURGE PROTECTIVE DEVICES

KEEP THIS PAGE FOR YOUR OWN RECORDS.

(1) What is Covered By This Limited Warranty

(A) Replacement of Product

Intermatic Incorporated (“Intermatic”) warrants to the original purchaser only, Intermatic AG3000G Surge Protective Devices (each a “Product”) shall be free from defects in

material or workmanship for a period of three years (36 months) from date of purchase or 39 months from date of manufacture. If the purchaser discovers a defect in material

or workmanship, the purchaser must promptly submit a warranty claim. Upon a determination by Intermatic that the Product is defective, Intermatic, shall correct any defect in

material or workmanship by replacing the Defective Product. Any repair, including both parts and labor, shall be at Intermatic’s expense. The foregoing remedy is the purchaser’s

exclusive remedy for a breach of warranty.

The product must be installed in the appropriate application in complete accordance with the installation instructions. All building wiring and other connections to the Product

must conform to all applicable national, state, and local electrical codes; the Product must not be opened, modiﬁed, exposed to extreme heat or cold, submerged or subjected

to abnormal use or service. All products must be used in accordance with the instructions provided with the Product and the purchaser shall be solely responsible for selecting a

Product model with speciﬁcations appropriate for the equipment to be protected. Intermatic shall determine, in its sole discretion, whether any Product returned by a purchaser

has been used in accordance with its instructions, is an appropriate model for the purchaser’s use thereof, and whether the Product is defective.

(B) Repair or Reimbursement for Damage to Properly Connected Equipment

In addition to the above described Product warranty, Intermatic warrants to the original purchaser of the Product for a period of three years from the date of purchase, the following:

In the event that any major household connected electrical equipment (as deﬁned below) is damaged (the “Damaged Equipment”) as a direct result of the failure of a Product to

protect the Damaged Equipment from Power Transients (as hereinafter deﬁned) and all other conditions are satisﬁed, Intermatic’s option, either repair the Damaged Equipment

or reimburse the purchaser of the defective product. The limit of Intermatic’s liability under this warranty shall be the Fair Market Value (as hereinafter deﬁned) of the Damaged

Equipment or the deductible amount of the original purchaser’s homeowners insurance policy, whichever is less. In no event shall Intermatic incur repair costs or reimburse the

purchaser for an amount in excess of $7,500.

As used herein, “major household connected electrical equipment” shall mean major household appliances and electronic devices, including refrigerators, freezers, air conditioners,

stoves and ovens, microwave ovens, clothes washers and/or dryers, dishwashers, audio and stereo equipment or components, video equipment, televisions and computers. Major

household connected electrical equipment that normally requires an additional connection such as phone/modem connection, antenna or cable connection or other temporary

or permanent connection must be properly connected to an Intermatic listed Surge Protection Device that incorporated surge protection for both AC (power) and all other input

connections. The Fair Market Value of the Damaged Equipment shall be the current value of the equipment speciﬁed in the most recent version of the Orion Blue Book (printed or

on-line edition) by Orion Research Corporation, or a comparable publication.

Promptly upon discovering any Damaged Equipment, the purchaser must submit a claim pursuant to the claim procedure provided below. In no event may a purchaser initiate a

claim later than (30) days after the Protected Equipment is damaged. In order to receive the Connected Equipment protection provided in this Section, all of the following conditions

must be satisﬁed with respect to the use of the Product: (a) the Product must be properly installed; (b) all building wiring and other connections to the Product and the Damaged

Equipment must conform to all applicable federal, state and local electrical codes; (c) no ground wires or ground connections in addition to the AC power source can be used

in connection with the Product or the Damaged Equipment; (d) Equipment with additional wiring or data/cable connections (as deﬁned above) must be properly connected to a

Listed Surge Protection Device (as noted above); and (e) the Product(s) and Protected Equipment must not be opened, modiﬁed, exposed to extreme heat or cold, submerged or

subjected to abnormal use or service.

For purposes of this Limited Warranty, a Power Transient shall mean over-voltage resulting from momentary voltage spikes or surges on an AC power line of magnitude that the

Product, according to its speciﬁcations, is designed to stop before such spikes or surges affect downstream equipment.

(2) What is Not Covered By This Warranty

Intermatic does not warrant (a) defects in the Product or damage to any equipment caused by the failure to properly install the Product, (b) damage caused by use of the Product for

purposes other than those for which it was designed, (c) damage caused by disaster such as ﬁre, ﬂood and wind, (d) damage caused by unauthorized attachments or modiﬁcation

of the Product, (e) damage to the Product occurring during the shipment, or (f) electrical disturbances exceeding published product speciﬁcations, (g) damage to the Product caused

by any other abuse or misuse by the purchaser, (h) damage due to direct or vicinity lightning strikes, this warranty applies to residential and commercial applications. This device

is not intended to provide protection during Utility voltage swells or loss of neutral conditions which are by deﬁnition not transient events and are not covered by this warranty.

(3) Disclaimer of Warranty

THE FOREGOING WARRANTIES ARE IN LIEU OF ALL OTHER EXPRESSED WARRANTIES. TO THE EXTENT ALLOWED BY LAW, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED IN DURATION OF THIS LIMITED WARRANTY.

(4) Limitation of Remedies

IN NO CASE SHALL INTERMATIC BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES BASED UPON BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE,

STRICT TORT, OR ANY OTHER LEGAL THEORY. SUCH EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, DAMAGE TO SOFTWARE, LOSS OF DATA, LOSS OF PROFITS, LOSS OF

SAVINGS OR REVENUE, LOSS OF USE OF THE PRODUCT OR ANY ASSOCIATED EQUIPMENT, COST OF CAPITAL, COST OF ANY SUBSTITUTE EQUIPMENT, FACILITIES OR SERVICES,

DOWNTIME, THE CLAIMS OF THIRD PARTIES INCLUDING CUSTOMERS, DAMAGE TO PROPERTY AND PERSONAL INJURY. SOME STATES DO NOT ALLOW LIMITS ON WARRANTIES OR

ON REMEDIES FOR BREACH IN CERTAIN TRANSACTIONS, IN SUCH STATES, THE LIMITS IN THIS PARAGRAPH AND IN PARAGRAPH (3) MAY NOT APPLY.

(5) Time Limit for Bringing Suit

No action arising out of any claimed breach of warranty may be brought more than one year after the cause of action has occurred.

(6) No Other Warranties

Unless modiﬁed in writing signed by both parties, this agreement is understood to be the complete and exclusive agreement between the parties, superseding all prior agreements,

oral or written, and all other communications between the parties relating to the subject matter of this agreement. No employee of Intermatic or any other party is authorized to

make any warranty in addition to those made in this agreement. This warranty is made by: Intermatic Incorporated/After Sales Service, 12429 Rojas Drive, EL Paso, TX 79928-

5201/815-675-7000 http://www.intermatic.com

(7) Claim Procedure

In order to submit a claim for warranty service the original purchaser must:

(A) Contact the Intermatic Insurance Claims Center at 1-800-270-7227 before having the damaged equipment repaired.

(B) Request that an Incident Claim Report be written regarding the damage including descriptions and model identiﬁcation (if available) of the equipment that was damaged.

Record the Warranty Claim Number for future reference.

(D) Send the INTERMATIC SURGE PROTECTIVE DEVICE to the Intermatic Warranty Coordinator at the address listed below. All returned devices must be plainly marked with the

Intermatic Warranty Claim Number.

(E) Send all of the following information in a single packet to the Intermatic Warranty Coordinator at the address listed below.

(1) Claimant’s name, address and telephone number.

(2) Original dated sales receipt for the Intermatic Surge Protection Device.

(3) Original report for repair work.

(4) The damage report

(5) A copy of the claim report by the homeowners (renter’s) insurance company or a copy of the policy showing the deductible amount exceeds the cost of the repair.

(F) Address all communications and products returns to:

Intermatic Warranty Coordinator

1950 Innovation Way, Suite 300

Libertyville, Illinois 60048

Attn: Surge Claim Processor

Product & Installation Information

Purchase date:

Installation date:

Installed by:

Point of installation:

Breaker ratings if applicable:
