Pagina 1/112

APPLIANCE

1. Upper rack

2. Foldable aps

3. Upper rack height adjuster

4. Upper spray arm

5. Lower rack

6. Cutlery basket

7. Lower spray arm

8. Filter Assembly

9. Salt reservoir

10. Detergent and Rinse Aid dispensers

11. Rating plate

12. Control panel

0000 000 00000

Service:

1011

1. On-O/Reset button with indicator light

2. Program selection knob

3. Start/Pause button with indicator light / Drain out

DAILY REFERENCE

GUIDE

CONTROL PANEL

PRODUCT DESCRIPTION

PLEASE SCAN THE QR CODE

ON YOUR APPLIANCE IN ORDER

TO HAVE MORE DETAILED

INFORMATION

THANK YOU FOR BUYING AN INDESIT PRODUCT.

In order to receive amore complete assistance, please

Before using the appliance carefully read Safety Instructions

guide.

FIRST TIME USE

SALT, RINSE AID AND DETERGENT

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the retaining

elastic elements from the upper rack.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and

on the machine’s functional components.

• It is mandatory that THE SALT RESERVOIR NEVER BE EMPTY.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher (see

PRODUCT DESCRIPTION) and must be lled when the green oat on the

cap of the salt reservoir is no longer visible.

1. Remove the lower rack and unscrew the

reservoir cap (anticlockwise).

2. Only the rst time you do this: ll the salt

reservoir with water.

3. Position the funnel (see gure) and ll the salt

reservoir right up to its edge (approximately

1 kg); it is not unusual for alittle water to leak

out.

4. Remove the funnel and wipe any salt residue

away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get

into the container during the wash program (this could damage the

water softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the pro-

cedure before the beginning of the washing cycle to avoid corrosion.

SETTING THE WATER HARDNESS

To allow the water softener to work in aperfect way, it is essential that

the water hardness setting is based on the actual water hardness in

your house. This information can be obtained from your local water

supplier.

The factory sets the default value for the water hardness:

• Switch on the appliance by pressing the ON/OFF button.

• Switch o the appliance by pressing the ON/OFF button.

• Hold down button START/Pause for 5 seconds.

• Switch on the appliance by pressing the ON/OFF button.

• The ON/OFF LED light will ash as many times as the level that was set.

• Set the desired water hardness level using the PROGRAM SELECTION

knob (see WATER HARDNESS TABLE).

• Switch o the appliance by pressing the ON/OFF button.

Setting is complete!

As soon as this procedure is complete, run aprogram without loading.

Only use salt that has been specically designed for dishwashers.

If the salt container is not lled, the water softener and the heating

element may be damaged as aresult of limescale accumulation.

Using of Salt is recommended with any type of dishwasher deter-

gent.

Water Hardness Table

Level

°dH

German degrees

°fH

French degrees

°Clark

English degrees

1 Soft 0 - 6 0 - 10 0 - 7

2 Medium 7 - 11 11 - 20 8 - 14

3 Average 12 - 16 21 - 29 15 - 20

4 Hard 17 - 34 30 - 60 21 - 42

5 Very hard 35 - 50 61 - 90 43 - 62

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser Ashould

be lled when when the dark optical indicator on the dispenser door C

becomes transparent.

1. Open the dispenser B by pressing and pulling up the tab on the lid.

2. Pour in the rinse aid (max.110 ml), making sure it does not overow

from the dispenser. If this happens, clean the spill immediately with

adry cloth.

3. Press the lid down until you hear aclick to close it.

NEVER pour the rinse aid directly into the appliance tub.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satised with the drying results, you can ad-

just the quantity of rinse aid used.

• Switch the dishwasher on using the ON/OFF button.

• Switch it o using the ON/OFF button.

• Press button START/Pause three times.

• Switch it on using the ON/OFF button.

• The START LED light will ash as many times as the level that was set.

• Set the level of rinse aid quantity to be supplied using the PROGRAM

SELECTION knob (see PROGRAMS TABLE).

• Switch it o using the ON/OFF button

Setting is complete!

If the rinse aid level is set to 1 (ECO), no rinse aid will be supplied.

Amaximum of 5 levels can be set according to the dishwasher model.

The factory setting is specic to the model, please follow instruction

above to check this for your machine

• If you see bluish streaks on the dishes, set alow number (2-3).

• If there are drops of water or limescale marks on the dishes, set amid-

range number (4-5).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device D.

Introduce the detergent into the dry dispenser Eonly. Place the

amount of detergent for pre-washing directly inside the tub.

1. When measuring out the detergent

refer to the mentioned earlier infor-

mation to add the proper quantity.

Inside the dispenser Ethere are indi-

cations to help the detergent dosing.

2. Remove detergent residues from

the edges of the dispenser and

close the cover until it clicks.

3. Close the lid of the detergent dis-

penser by pulling it up until the

closing device is secured in place.

The detergent dispenser automatically opens up at the right time

according to the program.

Usage of detergent not designed for dishwashers may cause mal-

function or damage to the appliance.

Product specificaties

Merk:	Indesit
Categorie:	Vaatwasser
Model:	Slimline DF9E 1B10
Apparaatplaatsing:	Vrijstaand
Soort bediening:	Knoppen
Ingebouwd display:	Nee
Gewicht:	27200 g
Breedte:	448 mm
Diepte:	555 mm
Hoogte:	820 mm
Netbelasting:	1900 W
Aantal couverts:	9 couverts
Automatische programma's:	Nee
Droogsysteem:	Statisch
Snoerlengte:	1.3 m
Uitgestelde start timer:	Nee
Resterende tijd indicatie:	Nee
Kinderslot:	Nee
Duur cyclus:	240 min
Geluidsniveau:	51 dB
Energie-efficiëntieklasse:	F
Gewicht verpakking:	29000 g
Breedte verpakking:	500 mm
Diepte verpakking:	675 mm
Hoogte verpakking:	890 mm
Verlichting binnenin:	Nee
Waterconsumptie per cyclus:	11.5 l
Stroom:	13 A
Geluidsemissieklasse:	D
Tijdsduur tot uitschakelen:	12 min
Aantal wasprogramma's:	5
Duur cyclus (snelwas programma):	40 min
Energieverbruik per 100 cycli:	78 kWu
Land van herkomst:	Polen
Douane productcode (TARIC):	84221100
Productafmeting:	Slimline (45 cm)
Kleur bedieningspaneel:	Wit
Bestek compartiment type:	Mand
Kuip materiaal:	Roestvrijstaal
Vloerindicatielampje:	Nee
Zout indicator:	Nee
Glansmiddel indicator:	Nee
Bescherming tegen overstromen:	Ja
Aantal temperatuurinstellingen:	3
Extra droog:	Nee
Glasbescherming:	Nee
Half-geladen:	Nee
Beladingssensor:	Nee
Afwasprogramma's:	Eco 50°C, Intensive 65°C, Mixed, Quick 45°C
Energieverbruik per cyclus:	0.78 kWu
Bovenste mand verstelbare hoogte:	Ja
Automatische deuropening:	Nee
Maximale warmwatertoevoertemperatuur:	60 °C
Temperatuur (max):	70 °C
Watertoevoer:	Koud
Aantal mandjes:	2 mand(en)
Stroomverbruik (ingeschakeld houden):	5 W
Stroomverbruik (indien uit):	0.5 W
Ingebouwde water verzachter:	Ja
Export Control Classification Number (ECCN):	84221100
AC-ingangsspanning:	220-240 V
AC-ingangsfrequentie:	50 Hz
Producthoogte:	Standaard (80-85 cm)
