Pagina 1/4

www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re tooﬁlmmakers

SFB150

Quick Start Guide

Stryder Fanless Bi-Color 150 Watt Fresnel LED

What’s Included

1 x 4” Fresnel Light Fixture

1 x Controller Box w/ V-Mount Plate

1 x Barn Door

1 x Yolk w/ Baby 5/8” Adapter

1 x Power Adapter

www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re tooﬁlmmakers

Getting Started

Thank you for buying the SFB150 Fresnel Light from ikan. Please carefully read the instructions and guide before operating the products. The guide

includes product usage and maintenance. When you operate the product, please make sure that you have read the instructions carefully.

All the content of the manual is based on up-to-date information; technical data subject to change without notice.

Structure

Overview

Absolute lighting control is right at your ﬁngertips with this Stryder Fanless 150 watt LED Fresnel Light with DMX. The impressive daylight LED features a

4” Fresnel lens with a spot to ﬂood beam range of 30 to 65°. Toss in the ability to accurately shape light with removable barn doors, dimming capabilities

between 0-100% (controlled in increments 5), and its ability to use traditional gel rings, mean that this workhorse of a light will undoubtedly become a

staple in your kit.

A. LCD Display

B. Color Temperature/

Conﬁrmation Knob

C. DMX Channel Adjustment

D. Brightness Knob

E. DMX Input

F. DMX Output

G. XLR Power Port

H. Yoke Adjustment Knob

J. Barn Door Locking Pin

K. Power Input (from control panel)

L. Focusing Knob

M. Power Switch

N. Power Out (to light ﬁxture)

P. V-Mount Battery Plate

Color Temperature Battery

Brightness

Color : 5600K B:

100%

Bright: 100%

B C D

H J

www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re tooﬁlmmakers

Notice & Maintenance

- Products must be placed on a stable, dry, ﬂat surface. Avoid exposure to sunlight and operating in an environment with high humidity or explosive gas.

- Don’t cover the fan vent. It will shorten the working life of the ﬁxture.

- Don’t knock or shake the lighting equipment during the operation.

- If the SFB150 isn’t working normally, please contact the Ikan repair department. Please don’t disassemble/re-assemble by yourself.

- Please place the SFB150 in a cool and dry place when you don’t use it for an extended period of time.

Speciﬁcations

Beam Angle 30 - 65 degrees

Build Material Aluminum

Control Local Knob Control and DMX In/Out

Cooling System Fanless Passive Cooling

Dimming Flicker Free Dimming, Onboard Dimming

Knob 10%-100% (minimal color shift)

Focusing Push Focus from 30 - 65
