Pagina 1/1
40-1/2"
1029mm
514mm
20-1/4"
13"
330mm
26"
660mm
19-1/4"
489mm
22"
559mm
279mm
11"
38-1/2"
978mm
AA
SECTION A-A
MOUNTING DETAIL
Ø 5/8"
4X
Ø 16mm
HOLE THRU
46-1/2"
1181mm
83"
2108mm
12-7/8"
327mm
27" MIN
686mm
914mm
36"
2318mm
91-1/4"
FLOOR LINE
2184mm
86"
3-7/8"
98mm
90-1/8"
2289mm
2-1/4"
57mm
RECESS FOR
WHEELCHAIR
ACCESS
1" IPS
SUPPLY
OPTIONAL
1" IPS
SUPPLY
3" DRAIN PIPE
4X
1/2" (12.7mm)
ANCHOR
BOLT ASSEMBLY
NOTES:
1. DIMENSIONS MAY VARY BY ± 1/2 INCH [13mm].
2. TO COMPLY WITH ANSI Z358.1-2009 FOR EMERGENCY EYEWASH OR EYE/FACE WASH AND SHOWER EQUIPMENT:
- UNIT SHALL BE INSTALLED IN ACCORDANCE WITH MANUFACTURER'S INSTRUCTIONS AND ACCEPTABLE PLUMBING PRACTICES.
- EYEWASH OR EYE/FACE WASH SHALL BE POSITIONED WITH NOZZLES NOT LESS THEN 83.8 CM (33 IN.) AND NO GREATER THAN
114.3 CM (45 IN.) FROM SURFACE ON WHICH USER STANDS AND 15.3 CM (6 IN.) MINIMUM FROM WALL OR NEAREST OBSTRUCTION.
- SHOWER SHALL BE POSITIONED SO THAT SHOWER HEAD IS NOT LESS THAN 208.3 CM (82 IN.) NOR MORE THAN 243.8 CM (96 IN.)
FROM SURFACE ON WHICH USER STANDS.
- SHOWER SPRAY PATTERN SHALL HAVE A MINIMUM DIAMETER OF 50.8 CM (20 IN.) AT 152.4 CM (60 IN.) ABOVE SURFACE ON WHICH
USER STANDS, AND CENTER OF SPRAY PATTERN SHALL BE LOCATED AT LEAST 40.6 CM (16 IN.) FROM ANY OBSTRUCTION.
3. FLOW RATE FOR EYE/FACE WASH IS 3.7 GPM AND 1.32 GPM FOR EYEWASH CONVERSION. BOTH EXCEED ANSI Z358.1-2009 STANDARD.
17-3/4"
36"
DRAIN SHOWER
3" INSIDE CAULK
(SUPPLIED)
(NOT SUPPLIED)
APPROVED:
DRAWN:
PART NUMBER
SCALE:
SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved.
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: HAWS@HAWSCO.COM
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
RTM
8/10/01
11
0002080194.D
8605WC
EMERGENCY SHOWER
1:1
1 1
FV
12/31/15
RVH
INSTALLATION
5036
2015
HM
