Assembly Instructions: (Galveston)4855-6
IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
1. PREPARING FOR INSTALLATION
Remove all of the contents from the carton. See
the important notes above. Shut off the power at
the circuit breaker and completely remove the old
strap.
assembly. One end of nipple (F) should be attached
tomountingstrap(A)withwasherandhexnut(C,D)
in place. The other end should have canopy loop (H)
attached.Attachmountingstrap(A)tothejunction
boxusingmountingscrews(B)andascrewdriver.
Tightensecurely.Unscrewcanopyloopcollar(I)from
canopylooptotesttheheight.Approximatelyhalf
ofthecanopyloop’sexteriorthreadsshouldbe
andadjusttheheightofnipple(F)andcanopyloop
(H)untilthedesiredheightisreached.
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
For Customer Service, contact
the place of purchase to arrange
for replacement parts.
BLACK
(Hot)
WHITE
(Neutral)
GREEN
(Ground)
HOUSE WIRES
SMOOTH
(Or Black)
FIXTURE WIRES
RIBBED
(Or White)
BARE COPPER
(Or Green)
UP - INSTALLATION
PLEASE NOTE:
Thisxturemaybe
mounted with the
socketsandglass
facingupordown.
Please decide how you
wouldlikethexture
tobehungandfollow
thecorresponding
instructions.
2. ASSEMBLING THE FIXTURE
Determinewhetheryouwouldlikethesocketsandglasstobemountedfacingupordown.
Ifyouwouldliketheglasstoface,turnxtureframe(R)sothatrings(S)sitclosetothetopoftheframeandthesocketsarepointedup.up
Gently placethextureonaatsurface.
Ifyouwouldliketheglasstoface,turnxtureframe(R)sothatrings(S)sitclosetothebottomoftheframeandthesocketsarepointeddown
down.Oneofrods(P)hasthexture’swriesrunningthroughit.Youwillalsoneedtoadjustthexture’swirestocreateenoughslackto
maneuvertherodthroughtheframetochangetheorientation.placethextureonaatsurface.Gently
Toploop(L)maybeonthexture’swires,butnotthreadedontothexture’sframeatpost(M)ofplate(T).Ifitisnotconnected,pullthexture’s
wiresthroughtoploop(L)beforetwistingtoploop(L)ontopost(M).Bymeasuring,determinethecorrectnumberofchainlinksneededfor
properhangingheight.Ifnecessary,useapairofplierstoopenandremoveanyexcesschain.Attachchainconnectors(K)toeachendof
chain(J)beforeattachingoneendofthechainconnector/chaintotoploop(L).Closethechainconnector.Connecttheotherchainconnector
(K) to canopy loop (H).
Haveanassistantholdthetoploopassembly.Attachoneendofrods(P)torings(S)ofthextureframe.Thenattachthefreeendofrods(P)
to plate (M).
Feedthexture’swiresupthroughtoploop(L)thenthroughchain(J)(everythreelinksorso).Slidecanopyloopcollar(I)andcanopy(G)onto
thechain/wire.
3. CONNECTING THE WIRES
Haveanassistantsupporttheweightofthexturewhilecompletingthewiring.Cutawayexcesswire.Threadthexture’swiresthrough
canopyloop(H)andnipple(F).Attachthexture’swirestothepowersupplywiresfromthejunctionbox.Connectblacktoblack(orsmooth);
whitetowhite(orribbed);groundtoground(greenorcopper).Twisttheendsofthewirepairstogether,andthentwistonawireconnector.
Makesurealltwistsareinthesamedirection.Ifthereisnogroundwire(greenorcopper)comingfromthejunctionbox,locategroundscrew
(E)onmountingstrap(A)andwrapthexture’sgroundwirearoundthegreengroundscrew(E).Useascrewdrivertosecuregroundscrew(E)
ontothemountingbracket.Tuckallwiresneatlyintothejunctionbox.
4. FINISHING THE INSTALLATION
Pushcanopy(G)uptotheceilingandslidecanopyloopcollar(I)upbeneaththecanopy.Tightlythreadcanopyloopcollar(I)ontocanopyloop
(H) to secure canopy (G) in place.
Slideglassshades(N)oversockets(Q)andsecureinplacewithsocketrings(O).Installlightbulbs(notprovided)inaccordancewiththe
xture’sspecications.Donotexceedthemaximumrecommendedwattage.
Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
A
B
C
G
H
I
J
K
L
M
O
P
Q
R
S
T
N
D
E
F
DOWN - INSTALLATION
S
P
T
O
N
Q
R
