Assembly Instructions: (Marco)6068-5/8
IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
PREPARING FOR INSTALLATION
Carefully remove all of the contents from the carton. See the
important notes above. Shut off the power at the circuit breaker
andcompletelyremovetheoldxturefromtheceiling,including
Fromthepartsbag,removethemountingstrapassembly.One
endofnipple(F)shouldbeattachedtomountingstrap(A)with
washerandhexnut(C&D)inplace.Theotherendshouldhave
canopy loop (H) attached.
Attachmountingstrap(A)tothejunctionboxusingmounting
screws(B)andascrewdriver.Tightensecurely.Unscrewcanopy
loop collar (I) from canopy loop (H). Pass canopy (G) over the
mountedcanopylooptotesttheheight.Approximatelyhalf
ofthecanopyloop’sexteriorthreadsshouldbeexposed,and
thecanopyloopcollarshouldtsnuglyontothecanopyloop.
Removecanopy(G)andadjusttheheightofnipple(F)and
canopyloop(H)untilthedesiredheightisreached.Removethe
canopy loop collar and canopy and place to the side.
ASSEMBLING THE FIXTURE
Placethebodyofthextureontoaatsurface.Threadcenter
column(N)tocenterpost(S)untiltight.Insertsteelwireropes
(O)topostholes(R)atthetopofsquareframe(P).Adjustthe
wires until frame (P) is level. Depress the cylinder lock at the top
cap to release the steel wire ropes (O)
Toploop(L)isonthexture’swires,butarenotattachedtotop
cap(M).Tightentoploop(L)ontothethreadsatthetopoftop
cap (M). Pull the wires until taut.
Bymeasuring,determinethecorrectlengthofchainneededfor
properhangingheight.Ifnecessary,useapairofplierstoopen
andremoveanyexcesschain.Attachoneofchainconnectors
(K)tochain(J).Passthexture’swiresthroughtoploop(L).
Pull the wires until taut. Attach one end of chain connector (K)
totoploop(L)andclosechainconnector(K).Feedthexture’s
wiresupthroughthechain(everythreelinksorso),pullingthe
wires until taut. Use the free chain connector (K) to attach chain
(J) to canopy loop (H). Slide canopy loop collar (H) then canopy
(G) down onto the chain/wires. Pull the wires until taut. Trim the
wirestothedesiredlengthplus8to10inches.
CONNECTING THE WIRES
Haveanassistantsupportthexture’sweightwhilecompleting
thewiring.Attachthexture’swirestothepowersupplywires
fromthejunctionbox.Connectblacktoblack(orsmooth);
whitetowhite(orribbed);groundtoground(greenorcopper).
Twisttheendsofthewirepairstogether,thentwistonawire
connector. Make sure all twists are in the same direction. If there
isnogroundwire(greenorcopper)comingfromthejunction
box,locategroundscrew(E)onmountingstrap(A)andwrapthe
xture’sgroundwirearoundthegreengroundscrew(E).Usea
screwdrivertosecuregroundscrew(E)ontomountingstrap(A).
Tuckallwiresneatlyintothejunctionbox.
FINISHING THE INSTALLATION
Pushcanopy(G)uptotheceilingandslidecanopyloopcollar(I)
upbeneaththecanopy.Tightlythreadcanopyloopcollar(I)onto
canopy loop (H) to secure canopy (G) in place.
Slideglass(T)overthesockets.
Installcandlesleeves(U),thenglass(T)beforeinstallingthe
lightbulbs(notincluded)inaccordancewiththexture’s
specications.Donotexceedthemaximumrecommended
wattage.
Your installation is now complete. Turn on the power and test
thexture.
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
For Customer Service, contact
the place of purchase to arrange
for replacement parts.
BLACK
(Hot)
WHITE
(Neutral)
GREEN
(Ground)
HOUSE WIRES
SMOOTH
(Or Black)
FIXTURE WIRES
RIBBED
(Or White)
BARE COPPER
(Or Green)
A
B
C
G
E
D
F
H
I
J
K
L
M
N
0
Q
R
T
U
S
P
