Assembly Instructions: (Bijoux)1998-5

IMPORTANT:

•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important notes

above.Removetheoldxturefromtheceiling,includingtheold

mountingstrap.

1.Takethemountingstrapassemblyfromthepartsbag.Oneend

ofnipple(C)shouldbeattachedtomountingstrap(A)withawasher

and hex nut in place. The other end should have canopy loop (F)

attached.

2.Useascrewdriverandmountingscrews(B)toattachmounting

strap(A)tothejunctionbox.(Note:Whenmountingstrap(A)is

properlyinstalled,abouthalfoftheexteriorthreadsofnipple(F)are

exposed,allowingcanopyloop(F)totsnuglyontonipple(C).You

maywanttotesttoensurethatwithcanopy(G)inplace,canopy

loop(F)tsontonipple(F).Aftertesting,removeeverythingfromthe

nippleandplaceasideforlater.)untilthedesiredheightisreached.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

For Customer Service, contact

the place of purchase.

FINISHING THE INSTALLATION

6.Pushcanopy(G)uptotheceilingandslidecanopyloopcollar(D)upbeneaththecanopy.Tightlythreadcanopyloopcollar(D)onto

canopy loop (F) to secure canopy (G) in place.

7.Slidecandlesleeves(L)overthesockets.Installlightbulbsinaccordancewiththexture’sspecications.Donotexceedthemaximum

wattage.

8.Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

3.Placethexture’sbody(M)ontoaatsurface.Threadtoploop

(H)ontopost(I).Bymeasuring,determinethecorrectnumberof

chainlinks(J)neededforproperhangingheight.Ifnecessary,usea

pair of pliers to open and remove any excess chain.

CONNECTING THE WIRES

5.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Cut

awaytheexcesswires.Threadthexture’swiresthroughthecanopyloopand

nipple.Refertothewiringdiagramandattachthexture’swirestothepower

supplywiresfromthejunctionbox.ConnectHottoHot,NeutraltoNeutral,and

GroundtoGround.Twisttheendsofthewirepairstogether,andthentwiston

awireconnector.Makesurealltwistsareinthesamedirection.Ifthereisno

housegroundwirecomingfromthejunctionbox,locategroundscrew(E)on

themountingbracket/mountingstrapandwrapthexture’sgroundwirearound

thegroundscrew.Useascrewdrivertotightenthetopofgroundscrew(E)onto

thewiresandintothemountingbracket/mountingstrap.Tuckthewiresintothe

junction box.

How to Identify the Fixture’s Wires

HotNeutralGround

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

House Wires

Fixture Wires

Hot

4. Attach one of chain connector (K) to each end of chain (J). Use one of chain connectors (K) to attach chain (J) to top loop (L) and close

thechainconnector.Feedthexture’swiresupthroughthechain(everythreelinksorso),pullingthewiresuntiltaut.Slidecanopyloop

collar(D)andcanopy(G)ontothechainandwires.Usethefreechainconnector(K)toattachchain(J)tocanopyloop(F).
