Instruction Part Number
P33710 Issue 2
How to use and care for your ATB Adjustable Breaking
Torque Wrench
Tool Specication
Models: ATB 2.5, 5 & 10 (Torque Range 0.5 – 10 N.m)
Accuracy: +/- 6% of Torque Setting
ISO 6789 Class: Type 2, Class A
Calibration Period: Every 12 Months or 5000 cycles (minimum)
Mechanism: Breaking - Incorrect tightening is unlikely
EPA Compliant: All Models
At the set torque, the handle moves
through an angle of 20° before resetting.
Safety & Maintenance
This Torque Tool is a precision instrument and should be used for its
intended purpose only
Only hold the tool using the handgrip
Always ensure that the tool is in correct alignment with the fastener
Torque tools should be regularly calibrated and inspected to ensure correct
operation
Ensure the tool is clean and free from oil, grease and water before use
Do not use extension bars to increase the leverage of the handle
Never dip into cleaning uid or petroleum
How to adjust your Torque Wrench
To adjust the torque setting:
Unlock the adjustment mechanism by pulling
the locking knob at the end of the handle.
To increase torque:
Rotate the handgrip clockwise until the required
torque is selected on the calibrated scale.
To reduce torque:
When adjusting, always approach the required
torque from a lower setting.
Rotate the handgrip anti clockwise passed your
setting, then increase torque to the required value.
To set torque:
Lock the adjustment mechanism by pushing the
locking knob at the end of the handle.
To use Torque Wrench:
The ATB Wrench is designed for use with
the specied range of open, ring and ared
spanner accessories, plus sockets when
used with a square drive (SD) ratchet attachment.
After use, set the ATB Wrench at the lowest
setting on the scale.
Servicing Information
Regular servicing of your Torque Tool by competent personnel is important to
ensure it continues to perform correctly.
Product specificaties
| Merk: | Gedore |
| Categorie: | Schroefmachine |
| Model: | ATB 5 |
| Gewicht: | 290 g |
| Soort: | Mechanisch |
| Kleur handvat: | Black, Blue |
| Nauwkeurigheid: | 6 procent |
| Lengte: | 220 mm |
| Type product: | Momentsleutel "Slipper" |
| Koppelbereik: | 1 - 5 Nm |
| Kleur steel: | Staal |
