QUICK START GU

XL VEGETABLE DICERS

MODELS

181XLDC14 - ¼", 181XLDC38 - ⅜", 181XLDC12 - ½", 181XLDC1 - 1"

Please read and comply with the instructions listed on this

document. To get the best service life and performance from your

machine, clean it thoroughly before and after use by following the

instructions listed below. Minimize the use of alkaline cleaners as

they may dull the finish and cause pitting.

SAFETY INSTRUCTIONS

CAUTION

Be careful when handling and operating the machine, as

the blades are very sharp. Always keep your hands away

from the blades.

OPERATION

1. Place the unit on a sturdy work surface.

2. Core, slice, or cut the produce to prepare it for

chopping.

3. Lift the handle and place the produce on the blades.

4. Remove hands from the cutting area.

5.Inoneuidmotion,bringthepushblockdowntoforce

the produce through the blades.

6. Lift push block and repeat as needed.

7. Clean the machine after chopping is complete using

the cleaning instructions below.

8. Do not chop produce larger than the opening in the

blade holder.

Note: to cut ¼" and ½", use ¼" push block. To cut ⅜", use

the push block. To cut 1, use the 1⅜""" push block.

CLEANING AND MAINTENANCE

1. Remove the handle, push block guide, bumpers, and

bladeandholderassemblyotheguiderods.

2. Wash the push block guide, push block, blade and

holder assembly, and frame thoroughly.

a. The push block can be removed from the push block

guide by removing the thumbscrews.

3. To disassemble the blade and holder assembly for

further cleaning:

a. Remove the screws and the blade holder plate.

b. Gently tap the blades and the blade spacers from

the blade holder.

4. To reassemble:

a. Place the blade holder on a sturdy surface with the

blade spacer pockets facing upward.

b. Insert the 4 blade spacers with their slots toward the

inner opening of the blade holder.

c. Insert blades with the sharp edge downward and

slots upward.

d. Insert blades with sharp edge and slots downward.

e. Reposition the blade holder plate and secure it

with screws.

f. Reposition the blade and holder assembly, bumpers,

push block, push block guide, and handle on

the frame.

5. When needed, lubricate the guide rods with mineral oil,

foodgradegreaseorparan.Do not use cooking oil.

REPLACEMENT PARTS

These parts can be purchased from the same location as the dicer.

ITEM NUMBERDESCRIPTION

181BAXL141/4" Blade Assembly

181BAXL383/8" Blade Assembly

181BAXL121/2" Blade Assembly

181BAXL11" Blade Assembly

181BL14XL1/4" Blade (26 Blades)

181BL38XL3/8" Blade (18 Blades)

181BL12XL1/2" Blade (12 Blades)

181BL1XL1" Blade (6 Blades)

181PBXL38Pusher Block for 3/8"

181PBXL1412Pusher Block for 1/4" & 1/2"

181PBXL1Pusher Block for 1"

181FT1Feet

181BUMPERBumper

07/2023
