PRODUCT DATASHEET
Features
PRODUCT DATASHEET
MA430 Series 400A
Clamp Meters + NCV
Compact size allows
measurements in tight
locations and Built-in
non-contact Voltage
detector with LED alert.
Three models to choose
from with True RMS
option and advanced
multimeter functions.
Features
•Built-in non-contact Voltage detector with LED alert
•Backlit LCD display
•1.2" (30mm) jaw size for conductors up to 350MCM
•True RMS models for MA430T/MA435T and multimeter
functions included on all clamp meters
•CAT III - 600V rating
•Data Hold
•Low battery indication and Auto Power Off
•Complete with test leads, general purpose Type K
bead wire temperature probe (for MA435T),
9V battery, and soft case
Specifications
MA430 / MA430TMA435TBasic Accuracy
Display counts20004000
True RMS— / YesYes
AC Current (max res.)400A (0.001A)400A (0.01A)±(2.5% + 8d)
DC Current (max res.)—400A (0.01A)±(2.5% + 5d)
AC Voltage (max res.)600V (0.1mV)600V (0.1mV)±(1.5% + 5d)
DC Voltage (max res.)600V (0.1mV)600V (0.1mV)±(1.5% + 2d)
Resistance (max res.)20MΩ (0.1Ω)40MΩ (0.1Ω)±(1.5% + 2d)
Frequency (max res.)—10Hz to 10kHz ±(1.5% + 2d)
Capacitance (max res.)—100µF (0.01nF)±(3.0% + 5d)
Temperature (max res.)—-4 to 1400°F/-20 to 760°C (0.1°)±(3% + 9°F/5°C)
Diode/ ContinuityYesYes
Dimensions/ Weight7.8x2.8x1.6" (197x70x40mm)/ 6.5oz (183g)
Ordering
MA430400A AC Clamp Meter + NCV ..............
MA430T400A True RMS AC Clamp Meter + NCV ............
MA435T400A True RMS AC/DC Clamp Meter + NCV ............
www.extech.com
Specifications subject to change without notice. Copyright © 2012-2013 FLIR Systems, Inc. All rights reserved including the right of reproduction in whole or in part in any form.
Rev. 10/10/13
