DV23‐en‐US_V1.02/15

USERGUIDE

DV23NonContact‐VoltageDetector

Safety

WARNING:RiskofElectrocution.Beforeuse,alwaystesttheVoltage

Detectoronoperationaknownlivecircuittoverifyproper

WARNING:RiskofElectrocution.Keephandsandfingersonthe

bodyoftheprobeandawayfromtheprobetipandtestedinductor

CAUTION:Read,understandandfollowSafety

RulesandOperating

Instructionsinthismanualbeforeusingthisproduct.

Donotattemptrepairs.Therearenouserserviceableparts.

Donotexposeunittoextremetemperaturesorhighhumidity

Donotusetheunitifitiswetordamaged

Donotapplymorethan

theratedvoltagebetweentheprobetip

andground.

Donotoperatewiththecaseopen.

Thissymbol,adjacentsymboltoanotherorterminal,

indicatesthethetheuserusermustrefertomanualfor

furtherinformation.

Thissymbol,adjacenttoaterminal,indicatesthat,under

normaluse,hazardousvoltagesmaybepresent.

Doubleinsulationsymbol

Specifications

VoltageSensitivity50Vto600VAC

Bandwidth50/60Hz

Detectiondistance<0.2”

OperatingTemperature32to104

F(0to40

C)

StorageTemperature14to122

F(‐10to50

C)

Altitude<7000’(2000m)

RelativeHumidity<95%RH

Batteries2x1.5‘AAA’type

Dimensions/Weight6.25x1”(159x25mm)/1.5oz(42g)

SafetyThisunitcomplieswith:

EMC:EN61326‐1:2006

LVD:EN610101:2010,EN61010‐031:2002+1:2008

UL:UL61010‐1,2

‐‐Edition,20050722

CAN/CSA‐C22.2No.610101,‐2

‐edition,200407

ForindooruseandinaccordancewithOvervoltageCategoryIV‐

600V,PollutionDegree2;conformstoCEstandards

ULListedTheULmarkdoesnotindicatethatthisproducthas

beenevaluatedfortheaccuracyofitsreadings.

1.Pocketclip

2.Batterycompartment

3.Probetip

4.Detectorconelamp

OperatingInstructions

Note:Fornewmeters,andremovethebatteryendcapthenremove

thebatteryinsulatingstrip(ifnecessary).

ACVOLTAGEDETECTION

1.theTouchprobeconductortip(3)tothehotorinsertintothe

hotsideoftheelectricaloutlet.

2.theIfACvoltageispresent,detectorconewill

illuminate(4)and

themeterwillbeep.

NOTE:Theconductorsinelectricalcordsetsareoftentwisted.For

bestresults,rubtheprobetipalongalengthofthecordtoassure

gettingthethetipincloseproximitytoliveconductor.

NOTE:Thedetectorisdesignedwithhigh

sensitivity.Staticelectricity

orothersourcesofenergymayrandomlytripthesensor.Thisis

normaloperation.

BATTERYINSTALLATION

1.theRemoveendcap(2)bygentlytwisting.

2.InserttwoAAAbatteries(observepolarity).

3.theReplaceendcap.



NOTE:Ifthemeterdoesnotworkproperly,check

thethatbatteriestoensurethey’refreshand

properlyinserted.

CLEANING

PleasewipethemeterwithclothDoadampasneeded.notuse

solventsorabrasiveswhencleaning.



Warranty

FLIRSystems,Inc.warrantsthisExtechInstrumentsbranddevicetobefreeofdefectsinpartsandworkmanship

foroneyearfromdateandofappliesshipment(asixmonthlimitedwarrantytosensorscables).Ifitshould

becomenecessarytoreturntheinstrumentforserviceduringorbeyondthewarranty

period,contactthe

CustomerServiceDepartmentforauthorization.Visitthewebsitewww.extech.comforcontactinformation.A

ReturnAuthorization(RA)numbermustbebeforeanyissuedproductisisreturned.Thesenderresponsiblefor

shippingcharges,insuranceanddamagedoesfreight,properpackagingtopreventintransit.Thiswarrantynot

apply

todefectsresultingfromactionofofthemisuse,userassuchimproperwiring,operationoutside

specification,impropermaintenanceorrepair,orunauthorizedmodification.FLIRSystems,Inc.specifically

disclaimsspecificanyimpliedwarrantiesorormerchantabilityfitnessforapurposeandbeanywillnotliablefor

direct,indirect,incidentalor

consequentialdamages.FLIR’stotalliabilityislimitedtorepairorreplacementofthe

product.Thewarrantysetforthaboveisinclusiveandnootherwarranty,whetherwrittenororal,orisexpressed

implied.

Calibration,Repair,andCustomerCareServices

FLIRSystems,Inc.offersrepairandcalibrationservicesfortheExtech

Instrumentsproductswesell.NISTcertificationformostproductsisalso

provided.CalltheCustomerServiceDepartmentforinformationon

calibrationservicesavailableforthisproduct.Annualcalibrationsshouldbe

performedtoverifymeterperformanceandaccuracy.Technicalsupportand



generalcustomerserviceisalsoprovided,refertothecontactinformation

providedbelow.

Allrightsrightreservedincludingtheofreproductionininwholeorinpartanyform

www.extech.com

SupportLines:U.S.(877)4398324;‐International:+1‐(603)3247800

TechnicalSupport:mail:[email protected]Option3;E‐

RepairReturns:&Option4;E‐mail:re[email protected]om

Productspecificationsaresubjecttochangewithoutnotice

Pleasevisitourwebsiteforthemostup‐to‐dateinformation

www.extech.com

FLIRCommercialSystems,Inc.,9

TownsendWest,Nashua,NH03063

ISO9001Certified
