PRODUCT DATASHEET

Features

PRODUCT DATASHEET

BR-CAM Series Borescope

Camera probes

Bright LED lights on camera

probe tip to illuminate dark

areas. Includes tip attachments

(hook, mirror, and magnet).

Features

• For use with Extech Models BR100, BR200, and

BR250 video borescopes

• Use different camera head sizes with the same video

borescope depending on the space requirements

• 4.5 mm and 5.2 mm come with a 1 m cable

• 9 mm and 17 mm cameras come with a

1 m, 2 m or 5 m cable

Specifications

BR-4CAMBR-5CAM-ABR-9CAM (-XM)BR-17CAM (-XM)

Resolution712 x 486 pixels640 x 480 pixels712 x 486 pixels640x480 pixels

LED Lights4 lights6 lights4 lights2 lights

Viewing Angle63°48°45°50°

Length1 m (3.3’)1 m (3.3’)

1 m (3.3’), 2 m (6.6’),

or 5 m (16.4’)

1 m (3.3’), 2 m (6.6’),

or 5 m (16.4’)

Outer diameter (O.D.)4.5 mm (0.178")5.2 mm (0.205")9 mm (0.35")17 mm (0.67")

Focus distance2 to 7 cm (0.8 to 2.8")3 to 8 cm (1.2 to 3.1")8 to 15 cm (3.2 to 5.9")8 to 15 cm (3.2 to 5.9")

Operating Temperature-10 to 50°C (14 to 122°F)-10 to 50°C (14 to 122°F)-10 to 50°C (14 to 122°F)-10 to 50°C (14 to 122°F)

Ordering

BR-4CAM4.5 mm Borescope Camera Head probe with 1 m cable ..............

BR-5CAM-A5.2 mm Borescope Camera Head probe with 1 m cable ..........

BR-9CAM9 mm Borescope Camera Head probe with 1 m cable ..............

BR-9CAM-2M9 mm Borescope Camera Head probe with 2 m cable .......

BR-9CAM-5M9 mm Borescope Camera Head probe with 5 m cable .......

BR-17CAM17 mm Borescope Camera Head probe with 1 m cable ............

BR-17CAM-2M17 mm Borescope Camera Head probe with 2 m cable .....

BR-17CAM-5M17 mm Borescope Camera Head probe with 5 m cable .....

www.extech.com

Specifications subject to change without notice. Copyright © 2012-2020 FLIR Systems, Inc. All rights reserved including the right of reproduction in whole or in part in any form.

Rev. 5/12/20

BR-17CAM

BR-4CAM

BR-9CAM

BR-5CAM-A

BR-4CAM UPC Code: 793950634004

BR-5CAM-A UPC Code: 793950635506

BR-9CAM UPC Code: 793950639009

BR-9CAM-2M UPC Code: 793950639023

BR-9CAM-5M UPC Code: 793950639054

BR-17CAM UPC Code: 793950630174

BR-17CAM-2M UPC Code: 793950631720

BR-17CAM-5M UPC Code: 793950631751
