Die EX6072PoE2 ist eine HighSpeed Gigabit Ethernet PCIExpress Karte mit Power over ----

Ethernet (PoE) Funktion. Sie ist mit zwei externen Ports ausgestattet. Jeder Port hat einen

eigenen Realtek Chip für eine optimale und schnelle Datenübertragung. Sie unterstützt alle PCI

-Express Slots von x1 bis x16. Der PCIExpress Bus unterstützt optimal die Leistung des -

schnellen Realtek Chipsatz. Die EX6072PoE2 gewährleistet so eine sichere Datenübertra---

gung und exzellente Performance von bis zu 1Gbit/s! Die EXPoE2 liefert isolierte 48V -6072--

über das EthernetKabel für PoE (PD) Geräte. Die Karte unterstützt auch CrossoverErkennung --

und AutoKorrekturFunktion für die einfache Netzwerkverkabelung. Im Lieferumfang der EX---

6072PoE2 ist ein Low Profile Bügel enthalten, welcher Ihnen auch einen Einbau in schmale PC-

- Gehäuse bis maximal 8cm Bauhöhe ermöglicht.

1

ANSCHLÜSSE & LEDS‘

BESCHREIBUNG & TECHNISCHE DATEN

AUFBAU

Anleitun

Vers. 1.0 / 21.07.22

E6072Po

Kompatibilität:PCIExpress p1-x1 bis x16-

Betriebssysteme:Windows 98SE / ME / 2000 / XP / Vista / 7 / 8.x / 10 / 11 / Server 20xx

Mac / Linux / UNIX / Novell

Anschlüsse:2x RJ45 Gigabit Ethernet Anschluss, 1x SATA 15Pin Anschluss,-

- 1x 4Pin Molex Anschluss

Lieferumfang:6072PoE2, Low Profile Bügel, Treiber CD, AnleitungEX--

Zertifikate:

2x RJ45 Anschluss

Status LEDs‘

RJ45 Anschluss:

RJ45 Anschluss

PinSignalPinSignalPinSignal

1BI_DA+4BI_DC+7BI_DD+

2BI_DA5BI_DC8BI_DD- - -

3BI_DB+6BI_DB -

J4:

SATA 15Pin -

Power Anschluss

vom PCNetzteil-

J3:

4Pin Molex -

Power Anschluss

vom PCNetzteil-

DRIVER INSTALLATION

Please note the following installation instructions. Because there are large differences between the

PC’s, we can give you only a general installation instructions for the EX-6072PoE-2. Please refer

your computers reference manual whenever in doubt.’

1.Turn off the power to your computer and any other connected peripherals.

2.Remove the mounting screws located at the rear and/or sides panels of your Computer and

gently slide the cover off.

3.Locate an available PCI-Express expansion slot and insert the card. Make sure that the card

is plugged in correctly.

4.Now install the power supply via the 4Pin Molex or SATA 15Pin connector. (see picture --

Connectors J3 or J4)

5.Then attach the card with a screw to the rear panel of the computer.

6.Gently replace your computers cover and the mounting screws.’

Windows 98SE / ME / 2000 / XP / Vista / 7 / Server 2003 & 2008R2

After starting Windows is recognizes a new .Please insert the Driver CD ““EthernetController-

into your CDRom drive (e.g. Drive D:) and open the folder LAN/RTL8111BGPlease select -„-“.

the folder with your operating system and install the driver (see Picture). Follow the hardware

assistant and finish the installation. Restart your PC in any case after installing the Important!

drivers.

Follow the installation instructions and complete the installation.

Windows will now install automatically you right driver for your particular operating system. After

the installation the operating system detects the card and automatically install them.

CHECK INSTALLED DRIVER

Open the >Device manager<.Now you should see at „Networkadapter“ the following new

entry's:

If you see this or a similar information the device is installed correctly.

Windows 8.x / 10 / 11 / Server 2012R2 / 2016 / 2019 / 2022

After the hardware installation, the operating system will recognize the device automatically and

install the drivers.

CHECK INSTALLED DRIVER

Open the >Device manager<.Now you should see at „Networkadapter“ the following new

entry's:

If you see this or a similar information the device is installed correctly.

Status LED´s:

LINK / Activity LED

PoE LED

CONNECTORS & LEDS‘

LED NameColorLED Function

LINK (ACT)Green

Steady on: Linked

Blinking: Data Transmission

PoE

Yellow

Steady on: PoE enabled

Off: PoE disabled

J3:

J4:

PinAssignmentPinAssignmentPinAssignment

13.3 Volt (Orange)5 Volt (precharge)12 Volt (pre 7 - 13 - charge)

23.3 Volt (Orange)85 Volt (Red)12 Volt (Yellow) 14

33.3 Volt (precharge)95 Volt (Red)- 1512 Volt (Yellow)

4Ground (Black) 10Ground (Black)

5Ground (Black) 11Reserve

6Ground (Black) 12Ground (Black)

To use the PoE function of the EX6072PoE2 and to supply the end devices with power, the --

card must be connected to the power connector of the PC power supply! Only one power

connector may be used J3 J4! OR

Please pay attention to the correct polarity!

Attention! Never connect or release the plug while the PC is supplied with power!

1 +12V2 GND3 GND4 +5V

To use the PoE function of the EX6072PoE2 and to supply --

the end devices with power, the card must be connected to

the power connector of the PC power supply! Only one

power connector may be used J3 J4! OR

Please pay attention to the correct polarity!

Attention! Never connect or release the plug while the

PC is supplied with power!

HARDWAREINSTALLATION
