Thank you for purchasing this RS232 to TTL/CMOS Converter It . is designed for

your PC, workstation, thin client, or server to provide an instant conversion

solution for the device that needs RS232 interface in TTL or CMOS voltage

level It . provides a DB9 female connector (DCE with standard RS232 signals, TXD, ,

RXD, RTS, CTS and GND) that can be connected directly to your PC s RS232 port’.

The product is powered by the RS232 signals so it does not need any DC power from

an external AC Power Adapter.

Features:

✓ Provides one RS232 to TTL/CMOS Adaption

✓ Supports 4-Signal RS232 Conversion: (TXD, RXD, RTS, CTS, GND)

✓ Supports DB9 Female (DCE) to DB9 Male (TTL/COMS) Connector Conversion

✓ Supports 5V and 3.3V Tolerance Signals

✓ Signal Levels are Inverted by the Co erter Similar to Standard RS232 but in nv

TTL/CMOS Swing Level

✓ Supports Baud Rate up to 115.2 Kbps

✓ Port-powered, no External Power Required

✓ No Driver Required for All Operating Systems

EX-47200

RS232 to TTL/CMOS Converter

1. Introduction

2. Layout: RS232 to TTL/CMOS Converter

Female DB9 RS232

(DCE)

TTL/CMOS

(5V/3.3V Tolerance)

RS232 to TTL/CMOS Converter

1. Use static electricity discharge precautions.

move possible static discharge potential from any objects that the converter Re

may come in contact with before installation. This can be accomplished by

touching a bare metal chassis rail after you have turned o the power.

2. Locate an unused RS232 port (with DB9 male connector, configured as PC’s

DTE) connect it to this Converter DB9 female connector connect the , ’s ,

TTL/CMOS RS232 Device to the Converter s DB9 male connector (with a ’

cable) .

DB9-Female Pin Assignment:

3. Installing the RS233 Isolator

4. RS232 Female DB9 Pin Assignments and Wiring

RS232

Device

5 1

9 6

9 Pins Signal

1 NC

2 T XD

3 R XD

4 NC

5 GND

6 NC

7 C TS

8 R TS

9 NC

NC = No connection

RS232 to TTL/CMOS Converter

DB9(Male, Host PC) to DB9(F ale on this product) Wiring: em ,

RS232

(DB9 female)

Signals

TTL/CMOS

(DB9 male)

3 (Input)

2 (Output)

7 (Input)

8 (Output)

5 (Signal GND)

R XD

T XD

C TS

R TS

GND

TXD-

RXD-

RTS-

CTS-

GND

3 (Output)

2 (Input)

7 utput) (O

8 (Input)

5 (Signal GND)

DB9-Male Pin Assignment:

DB9M(DTE,Host PC) DB9F(DCE, roduct) this p

1 DCD 1 DCD

2 RXD 2 TXD

3 TXD 3 RXD

4 NC 4 NC

5 GND 5 GND

6 NC 6 NC

7 RTS 7 CTS

8 CTS 8 RTS

5. TTL/CMOS Male DB9 Pin Assignments and Wiring

1 5

6 9

9 Pins Signal

1 NC

2 RXD-

3 TXD-

4 NC

5 GND

6 NC

7 RTS-

8 CTS-

9 NC

NC = No connection

Product specificaties

Merk:	EXSYS
Categorie:	Niet gecategoriseerd
Model:	EX-47200
Gewicht:	100 g
Breedte:	62 mm
Diepte:	32 mm
Hoogte:	16 mm
Gebruiksaanwijzing:	Ja
Soort serieële aansluiting:	RS-232
Certificering:	CE, FCC
Duurzaamheidscertificaten:	RoHS
Temperatuur bij opslag:	-40 - 75 °C
Intern:	Nee
Hostinterface:	USB
Seriële poort(en):	1
Bedrijfstemperatuur (T-T):	0 - 55 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 95 procent
Output interface:	Serie
