Copyright 2025 EtherWAN Systems, Inc.Page 1

All Rights Reserved

PD1042/PD1044

6/11/2025

PD1042/PD1044 Hardened RJ45 Surge Protector

Installation Guide

1 Unpacking

Unpack the items. Your package should

include:

➢One PD1042 or PD1044 Unit

➢One grounding cable

➢Wall and DIN-Rail mounting hardware

brackets/Screws

If items are missing or damaged, notify your

EtherWAN representative. Keep the carton

and packing material.

More information available at:

https://www.etherwan.com/us

For warranty information, visit:

https://www.etherwan.com/us/support/war

ranty-policy

2 Equipment Needed

➢Category 5e or better cables for RJ-45

ports

3 Attachments

➢DIN-rail installations: Attach the bracket

on the unit using the included screws and

then mount on a DIN-rail.

➢Wall installations: Attach the brackets on

the unit using the included screws and

then mount on a wall.

➢Choose a dry area with ambient

temperature between -40 and 75ºC (-40

and 167ºF).

➢Keep away from heat sources, sunlight,

warm air exhausts, hot-air vents, and

heaters.

➢Make sure there is adequate airflow

4 Connect to the Ports

The PD1042/PD1044 has the following ports:

➢2 or 4 10/100/1000M RJ45 ports labeled

IN

➢2 or 4 10/100/1000M RJ45 ports labeled

OUT

➢The device works in both directions (IN or

OUT). The device will protect equipment

on the opposite side of where the surge

occurs.

➢Connect one end to the IN or OUT ports

and connect the other end to the other

port types. Make sure the same port

number is used for IN and OUT.

➢If equipment on both sides of the line

need to be protected, it is necessary to

have a surge protector device installed at

each end.

➢When 2 surge protector devices are used,

it does not matter which port (IN/OUT) is

used to connect from one device to the

other.

5 Surge Protection

➢NOTE: The PD1042/PD1044 MUST be

grounded for the product to efficiently

work against surges. The grounding screw

is located on top of the unit.

➢NOTE: If shielded ethernet cables are

used, make sure the drain wires are

grounded at each end.

➢NOTE: The PD1042/PD1044 provides

protection against surges that come in

through the ethernet cable. It will NOT

protect against surges that come in

outside of the line. For equipment such

as outdoor WiFi Aps, lightning arresters

are recommended for such surges.

➢This device is designed to handle PoE

power passthrough of up to 90 watts

(802.3bt)

➢Device can handle up to 10KA surge

6 Application Distance

Limitation

➢The distance limitation of the total

installation path is 100 meters (328 ft).

This would be from network equipment at

one end to the network equipment at the

other end.

➢Install the surge device as close as

possible to the network equipment that

will be protected.
