11ENG IPERTU-SMRXXX 02 V01_0824

Semi Universal Analog Input & Analog Output Extension Modules

General Specicaons :

* Modules have 2 or 4 input channels according to module type

* Analog input types (each analog

input can be set in different type

individually) :

- Cu-50, PT100, PT1000, PTC, NTC, mV or

- V, mA

* ON/OFF kontrol, PID kontrol, AutoTune, SelfTune

* According to module type; 4 or 2 analog output (V/mA)

* Modbus RTU communicaon protocol with RS485

* USB Device (For device conguration)

* Modular connecon (up to 16 modules including itself)

* Led indicators:

- Power Supply, USB, RS-485

- Analog Input error led indicators

- Acve Output led indicators

SMR1P1-00-01-00-01_1

SMR1P1-00-03-00-03_1

SMR1P1-00-20-00-01_1

SMR1P1-00-21-00-03_1

Technical Specicaons

Module Type SMR1P1-00-01-00-01 SMR1P1-00-03-00-03 SMR1P1-00-20-00-01 SMR1P1-00-21-00-03

Supply Voltage - 28,8 VDC)

Power Consumpon 3W 4W 3W 4W

Communicaon RS-485 Modbus RTU

USB Device Mini USB, USB 2.0

Analog Inputs

Number of Inputs 4 2 4 2

Input Sensor TypeCu-50, PT-100, PT-1000, PTC, NTC, mV V, mA

Measurement Range

/ Resoluon

Cu-50 -200 ....

-328 ....

PT-100 -200 ...

-328 ...

PT-1000 -200 ...

-328 ...

PTC -50 .....

-58 .....

NTC -50 .....

-58 .....

mV 0 .........

V 0 ......... +2V / 1 mV

0 ......... +5V / 1 mV

0 ......... +10V / 1 mV

2 ......... +10V / 1 mV

mA 0 .........

4 .........

ADC resoluon 15 bit

Input Impedance

Voltage type inputs Other type inputs

mA type inputs

Overall accuracy % 0.2 (full scale)

Response me Per channel

300msec

150 msec 150 msec 150 msec

Average function

The aritmec average of the last read measurements according to the specied average

number of samples

Fault detecons 1- short circuit, 2- sensor break, 3- over range

Analog Outputs

Number of Outputs 2 x V / mA 4 x V / mA 2 x V / mA 4 x V / mA

Output range 0-10V or 0-20mA (only one tpe can be selected in the same me)

Overall accuracy % 0.5 (in the full scale measurement range)

Output Resistance For voltage output for current output

Response me ~200 msec

Led Indicators

Power

Always ON if the power input is in working limits, ashes 0.1s when undervoltage detected

Flashes 1s if the communicaon between Master and Slave module broken
