DOUBLE ANNIVERSARY BIG MUFF PI

Congratulations on your purchase of the DOUBLE ANNIVERSARY ELECTRO-

HARMONIXBIG MUFF PI fuzz pedal! This commemorative Muff is inspired by

the rich history ofthe BigMuffPiand Electro-Harmonix, with design elements that

pay homage tothe many faces ofthe Big MuffPi. TheDouble Anniversary BigMuff

Pi’slimited-edition, laser-etched, golden chassis you now hold in your hands

houses the sweet singing sustain of our most coveted violet Ram’s Head circuit.

CONTROLS AND CONNECTIONS

VOLUME Knob– Sets the output level.

TONE Knob– Provides a range of sounds from high treble to deep bass. As you

turn the knob clockwise the treble increases and bass decreases.

SUSTAIN Knob– Adjusts the amount of sustain and distortion.

Footswitch & Status LED– Use the footswitch to toggle between effect and

bypass. The device is active when the LED is lit. When the LED is off, the pedal is

in true bypass.

INPUT Jack– Plug the output of your instrument or another effects pedal into

the ¼” INPUT jack. The input impedance presented at this jack is 117kΩ.

AMPLIFIER Jack– Connect the device’s ¼” AMPLIFIER jack to the input of your

amplifier or another effects pedal. When the device is in bypass, the AMPLIFIER

jack is connected directly to the IN jack. The output impedance is 25kΩ.

POWER

The Double Anniversary Big Muff Pi is powered from a 9V battery or you can use

anoptional 9VDC AC Adapter capable ofdelivering atleast 25mA. Werecommend

the EHX 9.6DC-200 AC Adapter. The AC Adapter must have a center negative plug

that fits a 2.1mm center pin. The pedal has a current draw ofapproximately 12mA

at 9VDC. The external power supply should not exceed 14VDC.

Please Note: Using the wrong adapter or a plug with the wrong polarity

may damage your device and void the warranty.

Changing the BatteryTo change the 9V battery, remove the center screw on

the bottom of the device. Take off the battery plate and change the battery.

Avoid touching the circuit board while the battery plate is off. Replace the

battery plate and screw.
