Pagina 1/5
580W Peak Field LED Compact IP66
Framing Prole Fixture with CMY
Specications are subject to change without notice ©Elation Professional 03/19/2025
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
PROTEUS LUCIUS OPS
KEY FEATURES
P66 Outdoor Rated
High Eciency 580W 6,500K White LED Engine
Up to 33,500 Total Lumen Fixture Output
Peak Field engine for powerful projection at long distances
CMY Color Mixing and Variable CTO
5-Position Color Wheel with High CRI Filter
Complete FX System featuring Dual Rotating and Fixed Gobo Wheel,
Animation, Iris, Dual Prism, Dual Frost
ndexable Full Blackout Framing Syste
Wide Zoom Range from 5.5° to 50°
ELATION OPS - Designed for permanent outdoor installations
CX Extreme Marine Grade Coating
The PROTEUS LUCIUS OPS™ is a powerful yet compact IP66-rated LED prole xture oering outstanding
projection and beam qualities in any environment.
Providing up to 33,500 lumens output from its custom-designed Peak Field 580W 6,500K LED engine, the
PROTEUS LUCIUS OPS is the ideal xture for any outdoor or indoor application requiring superior output, bright
and powerful beams, and quiet operation, as well as stunningly precise gobos and colors. PROTEUS LUCIUS OPS
provides the designer a comprehensive FX package with 13 rotating and 7 xed glass gobos, full animation wheel,
overlapping dual prisms, dual frost and a high-speed iris. Its indexable framing system allows full-blackout shutter
cuts for precise beam shape control.
With a fast zoom range from 5.5° to 50° out of an impressively compact xture design, the PROTEUS LUCIUS OPS
has the power to cut through and make a statement on any stage.
ELATION OPS xtures are optimized for permanent exterior installations. Utilizing CX Extreme Marine Grade
Coatings, cabling and Stainless-Steel fasteners they are rugged, reliable and designed to withstand the elements.
DATA SHEET
580W Peak Field LED Compact IP66
Framing Prole Fixture with CMY
Specications are subject to change without notice ©Elation Professional 03/19/2025
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
PROTEUS LUCIUS OPS
SOURCE
580W 6,500K Bright White Peak Field LED
Engine
30,000 Hour Average LED Life*
*Test lab conditions. May vary depending on several factors including
but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-O
Cycling), Control, and Dimming.
PHOTOMETRIC DATA
33,500 Total Lumen Fixture Output
CRI 71+ (85+ with HCRI Filter)
2.5:1 Hotspot Ratio
Zoom Range 5.5° - 50°
Beam Angle 6° - 36.7°
Field Angle 7.6° - 51.3°
EFFECTS
Motorized Zoom
4 Rotating Full Blackout Framing Blades
+/-45° Framing Indexing
Full 360° Bi-Directional Animation Wheel
4-Facet and Linear Rotating Prisms
2 Variable Frost Filters (Light and Wash)
Internal Color, Framing, Prism, and Frost
Macros
Motorized Iris with Variable Pulse Eects
Variable 16-bit Dimming Curve Modes
High Speed Electronic Shutter and Strobe
DMX Controllable LED Refresh Rate
Pan Angle: 540°/630°
Tilt Angle: 250°
EXTERIOR FINISH
RAL9016 (custom colors available on request)
CX Extreme Marine Grade Coating
Stainless Steel 316 Fasteners
COLOR
CMY Color Mixing
Linear CTO Color Correction
5 Dichroic Colors including High CRI Filter
CONTROL / CONNECTIONS
2 DMX Channel Modes (43/68 Ch.)
DMX and RDM Protocol Support
(6) Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
NFC Support
10’ (3m) DMX In/Out combo cable
10’ (3m) Power cable
SIZE / WEIGHT
Length: 18.41 in (468mm)
Width: 14.6 in (370mm)
Height: 26.8in (682mm)
Center-to-Center Spacing 24.6in (626mm)
Weight: 89.9 lbs. (40.8 kg)
ELECTRICAL / THERMAL
AC 100-240V 50/60Hz
Max Power Consumption 1000W
-4° to 122°F (-20°C to 50°C)
BTU/hr (+/- 10%) 3239.5
INCLUDED ITEMS
Omega Brackets (x2)
Safety Cable
APPROVALS / RATINGS
CE | cETLus | FCC | IP66
SPECIFICATIONS
GOBOS
3 Gobo Wheels
6 Rotating Gobo (Wheel #1)
7 Rotating Gobos (Wheel #2)
7 Static Gobos (Wheel #3)
580W Peak Field LED Compact IP66
Framing Prole Fixture with CMY
Specications are subject to change without notice ©Elation Professional 03/19/2025
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
PROTEUS LUCIUS OPS
PRL734 PROTEUS LUCIUS OPS
TRIGGER
CLAMP 1741000032 Heavy Duty Wrap Around Hook Style Clamp
TOU027 N/A 5 ft. (1.5m) IP65 5pin XLR Cable
GOBOS | COLORS | ANIMATION WHEEL
ORDERING INFORMATION
ANIMATION WHEEL
