Instructions

ThankyouforpurchasingtheDP-415hybridDMXpack.Thisproducthasbeenthoroughlytested

atourfactoryforqualityandassurance.Yourcommentsregardingourproductsandservicesare

alwayswelcome.Youcanreachusbysendingane-mailtoinfo@elationlighting.com.Itisbotha

privilegeandpleasureservingyou.Pleasebesuretoreadtheseinstructionsbeforeoperatingthis

unitandkeeptheminasafeplaceforpossiblereferencelater.

TheDP-415isa4channelportabledimmer/switchpack.Eachoutputchannelcontainsdual15AmpEdison

socketsthatallowfortwodevicestobepluggedintoasinglechannel.Eachchannelcanthenbecontrolledvia

standardDMX512signalbyadjustingarelevantchannelfaderonyourDMXconsole.Thedipswitchesontheface

oftheunitallowyoutosettheDMXpatchaddressandoperationmodeforthepack.Standardbinarycodeshould

beusedtosetyourDMXpatchaddress.DipSwitch10isthe“Mode”switch.Thesettingofthisswitchdetermines

thepacks’operationmode,eitherasaDimmerorSwitchpack.Therearealso4channeloutputLED’sthatallowyou

toviewactivechannels.WhentheunitissettoDimmode,theseLED’sdiminrealtimeastherelevantchannelis

adjusted.ADMXsignalindicatorLEDisalsoincorporatedsothatwhenDMXsignalispresent,theLEDilluminates.

ProductDescription:

No.24-004-1516Rev1.1

Page1

Warning:

Thisunitmustbeearthed.

Keeptheunitdry,donotexposeittowaterorhighlevelsofhumidity.

Donotallowforanyflammableliquidstocomeinclosecontactwiththeunit.

Technicalrepairsshouldbeperformedbyanauthorizedtechnician.

Donotoperatethisunitiftheinternalcomponentsareexposed.

Whenreplacingfuses,alwaysreplacewiththesametypeandvalue.

Introduction:

TheDP-415wasdesignedtobemountedonanyformofpipeusinganapprovedriggingclamporontoanyflat

surfaceviahardwarethatisnotincludedwiththeproduct.

Tofastenaclamptotheunit,werecommendthatyouuseeitherofthe

twosuppliedcenterholes.Oneisonthetopsideandtheotherisontherear.Usetheonethatbettersuitesyour

rig.Anothermeansofhangingtheunit,isbyturningtherearpanelaround180º.Youwillneedaphillipshead

screwdrivertoreversethepanel.Disconnectthepowercord,removethefourphillipsheadscrewsonthe

backoftheunit,reversethepanelsotheflangedsideisfacingoutandreplacethefourphillipsheadscrews.

Thiswillallowyoutohangthepackontoany2”pipe

Thefinalmeansofmountingthisunitisontoaflatsurface

whereyoucansecureatleasttwobolts.Thismeansanexposedwoodbeam,metalbeam,wallthatyoucan

determinehasenoughsupporttoholdtheunitsweight,etc...Therearethreeholesonthebackpanelsuppliedfor

thisformofmounting.Useatleasttwoofthem,(preferably,thetwooutsideholes)withatleast2”lagbolts.

Note:thereshouldalwaysbeatleast12”of

clearancebetweenthepackandanythingsurroundingit.Itisalsorecommendedthatyouuseasafety

cablewhenevermountingoverhead.

units'

(Ifyouusethismethodtohangtheunit,youmustusea

safetycabletoensuretheunitdoesnotfalldown).

Mounting:

TheDP-415issuppliedwitha15Amp,12gaugepowerlinecord.Plugthelinecordintoaservicecapableof

supplingupto15ampstothepack.Lamploadsshouldbepluggedintothedual15AmpEdisonsocketswhichare

fittedonthesidesofthepackandareclearlymarkedonthefrontpanel.

.Besuretonotoverloadanychannelasthismayresultinblownfusesandmalfunction.Usinga

3pinXLR,DMXcable,connectoutofyourDMXconsoleorpreviousfixtureinlineandintotheDMXINofthe

DP-415.ConnectoutoftheDP-415,DMXOUT,andintotheinputofthenextdeviceinline.SetDipSwitchesas

required(SeePage3-“SetDMXAddress”).ItisrecommendedthatthelastpackorfixtureinlineincludeaDMX

terminatorintotheOutput.Thiswillminimizedatatransmissionerrors.

Eachchannelcanacceptaloadofupto5

Ampsor600Watts

Connections:
