User Instructions
ELAR EX TRIFLOOD HP Introduction
Elation Architectural - www.elationlighting.com - ELAR EX TRIFLOOD HP - Page 2
7/12
Unpacking: Thank you for purchasing the ELAR EX TRIFLOOD HP by
Elation Architectural®. Every ELAR EX TRIFLOOD HP has been thor-
oughly tested and has been shipped in perfect operating condition.
Carefully check the shipping carton for damage that may have occurred
during shipping. If the carton appears to be damaged, carefully inspect
your xture for any damage and be sure all accessories necessary to
operate the unit has arrived intact. In the case damage has been found
or parts are missing, please contact our customer support number for
further instructions. Do not return this unit to your dealer without rst
contacting customer support.
Introduction: The ELAR EX TRIFLOOD HP is part of Elation Archi-
tectural® continuing pursuit for creating high quality affordable intelli-
gent fixtures. The ELAR EX TRIFLOOD HP is a powerful DMX intelligent
RGB LED wash. This wash is light weight and compact which makes
it a great piece for mobile DJ’s and clubs. The unit has 4 operating
modes; Auto Run mode, Program mode, RGB mode, and DMX Con-
trolled. This unit can be used as a stand alone unit or in a master-slave
conguration.
Customer Support: ©Elation® provides a customer support line, to
provide set up help and to answer any question should you encounter
problems during your set up or initial operation. You may also visit us
on the web at www.elationlighting.com for any comments or sugges-
tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacic Standard Time.
Voice: (323) 582-3322
Fax: (323) 832-9142
E-mail: support@elationlighting.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
©Elation customer support.
PLEASE recycle the shipping carton when ever possible.
ELAR EX TRIFLOOD HP
ELAR EX TRIFLOOD HP Safety Precautions
Elation Architectural - www.elationlighting.com - ELAR EX TRIFLOOD HP - Page 4Elation Architectural - www.elationlighting.com - ELAR EX TRIFLOOD HP - Page 3
ELAR EX TRIFLOOD HP Warranty Registration
ELAR EX TRIFLOOD HP Features
To optimize the performance of this product, please read these operat-
ing instructions carefully to familiarize yourself with the basic operations
of this unit. These instructions contain important safety information
regarding the use and maintenance of this unit. Please keep this manual
with the unit, for future reference.
ELAR EX TRIFLOOD HP General Instructions
• Multi-Colors
• Tri LEDs - 3 LEDs Per Lens
• Built in Microphone
• DMX-512 protocol
• 7 DMX Modes: 1 Channel Mode, 2 Channel Mode, 3 Channel
Mode, another 3 Channel Mode, 4 Channel Mode, 6 Channel
Mode, & 7 Channel Mode
• Dimming 0-100% in 2 Channel Mode, 3 Channel Mode, 4 Channel
Mode, 6 Channel Mode, & 7 Channel Mode.
• Daisy Chain Units Together in DMX Mode
• Daisy Chain Units Together via Power Cord
The ELAR EX TRIFLOOD HP carries a two year limited warranty.
Please fill out the enclosed warranty card to validate your purchase.
All returned service items whether under warranty or not, must be
freight pre-paid and accompany a return authorization (R.A.) number.
The R.A. number must be clearly written on the outside of the return
package. A brief description of the problem as well as the R.A. number
must also be written down on a piece of paper included in the ship-
ping carton. If the unit is under warranty, you must provide a copy of
your proof of purchase invoice. You may obtain a R.A. number by con-
tacting our customer support team on our customer support number.
All packages returned to the service department not displaying a R.A.
number on the outside of the package will be returned to the shipper.
• Be sure that the local power outlet match that of the required volt-
age for your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break o the ground
prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never open this unit, it is factory sealed for a reason.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to the point they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 15 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances (inclu-
d ing amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance does not appear to operate normally or exhibits a
marked change in performance.
