Pagina 1/40

GS-3005P

User Manual

11-2020 / v1.1

CONTENTS

Chapter 1 Safety and Regulatory ........................................................... 4

Chapter 2 Introduction ......................................................................... 5

2-1 Overview ............................................................................................................................... 5

2-2 Package contents .................................................................................................................. 5

2-3 Features ................................................................................................................................. 6

2-4 Product Components ............................................................................................................ 7

2-4-1 Ports ............................................................................................................................... 7

2-4-2 LED Indicators ................................................................................................................ 8

Chapter 3 Installation ........................................................................... 9

3-1 Placement Tips ...................................................................................................................... 9

3-2 Desktop Installation .............................................................................................................. 9

Chapter 4 Getting Started .................................................................... 10

4-1 Power ................................................................................................................................... 10

4-1-1 Connecting to Power ................................................................................................... 10

4-1-2 Connecting to the Network ........................................................................................ 11

4-1-3 Power over Ethernet (PoE) Considerations................................................................ 12

4-1-4 Starting the Web-based Configuration Utility ........................................................... 13

4-1-5 Browser Restrictions ................................................................................................... 13

4-1-6 Launching the Configuration Utility ........................................................................... 13

4-2 Logging In ............................................................................................................................. 14

Chapter 5 Web-based Switch Configuration ......................................... 15

5-1 System Information ............................................................................................................ 16

5-2 Management ....................................................................................................................... 17

5-3 Port ...................................................................................................................................... 18

5-4 VLAN .................................................................................................................................... 19

5-4-1 IEEE 802.1Q VLAN ........................................................................................................ 19

5-5 Link Aggregation ................................................................................................................. 20

5-6 Port Mirror .......................................................................................................................... 21

5-7 QoS....................................................................................................................................... 22

5-7-1 Disable QoS ................................................................................................................. 22

5-7-2 Port-Based QoS ........................................................................................................... 23

5-7-3 IEEE 802.1p QoS .......................................................................................................... 25

5-8 Storm Control ...................................................................................................................... 27

Product specificaties

Merk:	Edimax
Categorie:	Schakelaar
Model:	GS-3005P
Kleur van het product:	Zwart
Gewicht:	390 g
Breedte:	84 mm
Diepte:	193 mm
Hoogte:	26 mm
Stroombron:	AC/DC
LED-indicatoren:	Activity, PoE, Power, Status
Stroom:	1.3 A
DC voltage input:	55 V
Certificering:	FCC Class A, CE
Netwerkstandaard:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3p, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x
Temperatuur bij opslag:	-40 - 70 °C
Upgraden van firmware mogelijk:	Ja
Web-gebaseerd management:	Ja
Luchtvochtigheid bij opslag:	5 - 90 procent
Rack-montage:	Nee
Vermogenstoevoer inclusief:	Ja
Quality of Service (QoS):	Ja
VLAN=ondersteuning:	Ja
Virtuele LAN-functies:	Multicast VLAN
Power over Ethernet (PoE):	Ja
Switchingcapaciteit:	10 Gbit/s
MAC-adrestabel:	4000 entries
10G support:	Ja
Datastroombeheer:	Ja
IGMP snooping:	Ja
Switch type:	Managed
Aantal basis-switching RJ-45 Ethernet-poorten:	5
Netstekker:	DC-in ingang
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Jumbo Frames ondersteuning:	Ja
Full duplex:	Ja
Koperen ethernetbekabelingstechnologie:	10BASE-T, 100BASE-T, 1000BASE-T
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
Totaal Power over Ethernet (PoE)-budget:	60 W
Aantal Power over Ethernet plus (PoE +)-poorten:	4
Verzending snelheid:	7.4 Mpps
Jumbo frames:	9000
Broadcast stormbeheer:	Ja
Bescherming lus:	Ja
Store-and-forward:	Ja
Vermogen per poort Power over Ethernet (PoE):	30 W
Packet forwarding rate (10 Mbps):	14880 pps
Packet forwarding rate (100 Mbps):	148800 pps
Packet forwarding rate (1 Gbps):	1488000 pps
