ES V2 V2- 3305P / ES- 3308P

Quick Installation Guide

09 201- 3 / v1.0

publicaon may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language, in any form or by

any means, electronic, mechanical, magnec, opcal, chemical, manual or

otherwise, without the prior wrien permission from Edimax Technology Co.,

Ltd.

Edimax Technology Co., Ltd. makes no representaons or warranes, either

expressed or implied, with respect to the contents hereof and specically

disclaims any warranes, merchantability, or tness for any parcular purpose.

Edimax Technology Co., Ltd. reserves the right to revise this publicaon and to

make changes from me to me in the contents hereof without the obligaon to

nofy any person of such revision or changes.

The product you have purchased and the setup screen may appear slightly

dierent from those shown in this QIG. The specicaon subject to change is

without noce. Please visit our web site www.edimax.com for the update. All

brand and product names menoned in this manual are trademarks and/or

registered trademarks of their respecve holders.

Edimax Technology Co., Ltd.

Add: No. 3, Wu‐Chuan 3rd Rd., Wu‐Ku Industrial Park, New Taipei City, Taiwan

Tel: +886‐2‐77396888

Email: sales@edimax.com.tw

PRODUCT INTRODUCTION

Model:

ES-3305P 5 Port Fast Ethernet Desktop Switch V2:

ES-3308P : 8 Port Fast Ethernet Desktop Switch V2

Package Contents

Before you start using this switch please check there is anything missing in the , if

package, and contact your dealer to claim the missing item(s):

 Fast Ethernet Desktop switch

 User manual

 Power Adapter

 USB Power Cable

Front Panel

5 Port Fast Ethernet Desktop Switch

8 Port Fast Ethernet Desktop Switch

LED Status:

LED Name

Light

Status

Descripon

PWR

Switch is on

O

Switch is o

LNK/ACT

Corresponding port is connected

O

Corresponding port is not connected

Flashing

Corresponding port is acve and transferring

/receiving data.

PWR LED

LNK/ACT LEDs - 5 1

LNK/ACT LEDs 1 - 8

PWR LED

Product specificaties

Merk:	Edimax
Categorie:	Schakelaar
Model:	ES-3305P V2
Kleur van het product:	Zwart
Gewicht:	92 g
Breedte:	98 mm
Diepte:	71 mm
Hoogte:	25.5 mm
Gebruikershandleiding:	Ja
LED-indicatoren:	Ja
Meegeleverde kabels:	USB
Vermogensverbruik (max):	1.07 W
DC voltage input:	5 V
Certificering:	CE, FCC Class B
Duurzaamheidscertificaten:	CE
Ethernet LAN, data-overdrachtsnelheden:	10, 100 Mbit/s
Netwerkstandaard:	IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Temperatuur bij opslag:	-20 - 70 °C
Luchtvochtigheid bij opslag:	5 - 90 procent
Rack-montage:	Nee
Naleving van duurzaamheid:	Ja
Vermogenstoevoer inclusief:	Ja
Power over Ethernet (PoE):	Nee
Stapelbaar:	Nee
Switchingcapaciteit:	1 Gbit/s
MAC-adrestabel:	1024 entries
10G support:	Nee
Datastroombeheer:	Ja
Switch type:	Unmanaged
Aantal basis-switching RJ-45 Ethernet-poorten:	5
Fast Ethernet (koperen) ports kwantiteit:	5
Switch-laag:	L2
Type basis-switching RJ-45 Ethernet-poorten:	Fast Ethernet (10/100)
Full duplex:	Ja
Koperen ethernetbekabelingstechnologie:	10BASE-T, 100BASE-TX
Auto-negotiation:	Ja
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
Verzending snelheid:	0.1488 Mpps
Fanloos:	Ja
Ondersteundende kabel types:	Cat3, Cat4, Cat5
Half-duplex:	Ja
