Draytek VigorAP 962C Handleiding

Draytek Access point VigorAP 962C

Bekijk gratis de handleiding van Draytek VigorAP 962C (128 pagina’s), behorend tot de categorie Access point. Deze gids werd als nuttig beoordeeld door 3 mensen en kreeg gemiddeld 4.4 sterren uit 2 reviews. Heb je een vraag over Draytek VigorAP 962C of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/128

VigorAP 962C

802.11ax Ceiling-mount Access Point

User’s Guide

Version: 1.2

Firmware Version: V5.0.5

Date: June 23, 2025

Intellectual Property Rights (IPR) Information

Copyrights

may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any

language without written permission from the copyright holders.

Trademarks

The following trademarks are used in this document:

 Microsoft is a registered trademark of Microsoft Corp.

 Windows, Windows 10, 11 and Explorer are trademarks of Microsoft Corp.

 Apple and Mac OS are registered trademarks of Apple Inc.

 Other products may be trademarks or registered trademarks of their respective manufacturers.

Safety Instructions and Approval

Safety

Instructions

 Read the installation guide thoroughly before you set up the device.

 The device is a complicated electronic unit that may be repaired only be authorized and

qualified personnel. Do not try to open or repair the device yourself.

 Do not place the device in a damp or humid place, e.g. a bathroom.

 The device should be used in a sheltered area, within a temperature range of +0 to +40 Celsius.

 Do not expose the device to direct sunlight or other heat sources. The housing and electronic

components may be damaged by direct sunlight or heat sources.

 Do not deploy the cable for LAN connection outdoor to prevent electronic shock hazards.

 Do not power off the device when saving configurations or firmware upgrades. It may damage

the data in a flash. Please disconnect the Internet connection on the device before powering it

off when a TR-069/ ACS server manages the device.

 Keep the package out of reach of children.

 When you want to dispose of the device, please follow local regulations on conservation of the

environment.

Warranty

We warrant to the original end user (purchaser) that the device will be free from any defects in

workmanship or materials for a period of two (2) years from the date of purchase from the dealer.

Please keep your purchase receipt in a safe place as it serves as proof of date of purchase. During the

warranty period, and upon proof of purchase, should the product have indications of failure due to

faulty workmanship and/or materials, we will, at our discretion, repair or replace the defective

products or components, without charge for either parts or labor, to whatever extent we deem

necessary tore-store the product to proper operating condition. Any replacement will consist of a

new or re-manufactured functionally equivalent product of equal value, and will be offered solely at

our discretion. This warranty will not apply if the product is modified, misused, tampered with,

damaged by an act of God, or subjected to abnormal working conditions. The warranty does not

cover the bundled or licensed software of other vendors. Defects which do not significantly affect the

usability of the product will not be covered by the warranty. We reserve the right to revise the

manual and online documentation and to make changes from time to time in the contents hereof

without obligation to notify any person of such revision or changes.

Be a Registered

Owner

Web registration is preferred. You can register your Vigor router via https://myvigor.draytek.com.

Firmware & Tools

Updates

Due to the continuous evolution of DrayTek technology, all devices will be regularly upgraded. Please

consult the DrayTek web site for more information on newest firmware, tools and documents.

https://www.draytek.com

Product specificaties

Merk:	Draytek
Categorie:	Access point
Model:	VigorAP 962C
Kleur van het product:	Wit
Gewicht:	812.6 g
Breedte:	208 mm
Diepte:	32.1 mm
Hoogte:	208 mm
Gewicht verpakking:	1170 g
Breedte verpakking:	355 mm
Diepte verpakking:	235 mm
Hoogte verpakking:	80 mm
Type verpakking:	Doos
Plaatsing:	Ceiling, Wall
Montage gereedschap:	Ja
Meegeleverde kabels:	LAN (RJ-45)
Snelstartgids:	Ja
Land van herkomst:	Taiwan
Aantal Ethernet LAN (RJ-45)-poorten:	1
Vermogensverbruik (max):	23 W
MIMO:	Ja
Aansluiting voor netstroomadapter:	Ja
Interface:	RJ45
Ethernet LAN, data-overdrachtsnelheden:	10,100,1000,2500 Mbit/s
Netwerkstandaard:	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ondersteunde beveiligingsalgoritmen:	HTTPS, OWE, SNMP, SNMPv2, WPA, WPA-AES, WPA2, WPA2-AES, WPA2-Enterprise, WPA2-Personal, WPA3, WPA3-Enterprise, WPS
Soort antenne:	Intern
Aantal gebruikers:	256 gebruiker(s)
Temperatuur bij opslag:	-20 - 70 °C
Upgraden van firmware mogelijk:	Ja
Web-gebaseerd management:	Ja
Reset button:	Ja
MAC adres filtering:	Ja
IP-adresfilter:	Ja
DHCP server:	Ja
MIMO-type:	Multi User MIMO
2,4 GHz:	Ja
5 GHz:	Ja
Quality of Service (QoS):	Ja
VLAN=ondersteuning:	Ja
Wifi Multimedia (WMM)/(WME):	Ja
Snelle roaming:	Ja
DHCP client:	Ja
IPv4- & IPv6-functies:	Dual stack IPv4/IPv6
Power over Ethernet (PoE):	Ja
IGMP snooping:	Ja
Maximale overdrachtssnelheid van gegevens (2.4 GHz):	1200 Mbit/s
Maximale overdrachtssnelheid van gegevens (5 GHz):	4800 Mbit/s
DC voltage bereik:	54 V
Full duplex:	Ja
Draadloze isolatie:	Ja
AC-ingangsspanning:	5 - 12 V
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 90 procent
Introductie jaar:	2024
Aantal SSID-ondersteuningen:	16
Spread spectrum methode:	OFDMA
Remote Authentication Dial-In User Service (RADIUS):	Ja
Garantieperiode:	2 jaar
Wi-Fi-roaming:	Ja
Bandbreedteaansturing:	Ja
Airtime Fairness (ATF):	Ja
DHCP snooping:	Ja
Load balancing:	Ja
Opdrachtregelinterface (CLI):	Ja
Type Power over Ethernet (PoE) ondersteunt:	Passive PoE
Introductie maand:	Januari
User Interface:	WEB
