Pagina 1/1

DSCPS3 V.001

FUNCTIONS

FunctionNameNumber

Screenshot, record video

Select & Pause

Controller power button / activate controller / back to main menu

Reset the controller

Directional joystick / activates an in-game command (depending on game settings)

Action - activates an in-game command (depending on game settings)

8-position directional action button - activates in-game commands (depending on game settings)

Directional joystick / activates an in-game command (depending on game settings)

Action - activates an in-game command (depending on game settings)

3/4/5/6

11/12/13/14

Start

Square / Triangle / Circle / Cross

Select

Home button

Reset hole

R1 / R2 / L1 / L2

Right analog joystick / R3

Left analog joystick / L3

D-Pad

Note:

The new controller is with low power, please charge the controller with provided cable before use.

For PS3™

Wireless

1 Please connect the controller and PS3™ console by the provided USB cable.

2 Wait for 3-5 seconds, please unplug the cable to disconnect the controller and console.

3 When 4 LEDs flash, controller is in connecting mode.

4 Once the controller and console connected successfully, the player LED stays on.

5 After the first-time connection through cable, press ‘Home’ button to activate console.

Wired – Plug & Play

1 Please connect the controller and PS3™ console by the provided USB cable, the controller will be automatically connected to the PS3™ console.

2 Once the controller and your console connected successfully, the player LED stays on.

PAIRING STEPS

• When charging - the 4 LEDs will flash slowly.

• Once fully charged - the LEDs stay on.

Note: charging cable with both data and charging functions.

CHARGING

SPECIFICATION

Cable length

Cable connector

Wireless connection

Bluetooth transmission distance

Battery type

Battery capacity

Charging hour

Play hour

1.2m

USB-A to Mini B

Bluetooth5.0

≦8m

Li-ion

600mAh

3-4 hours

10 hours

Input power rating

Voltage

Operating temperature

Radio frequency

Frequency band

Maximum radio-frequency

Mass

DC5V/ 200mA

DC3.6V -- 4.2V

0---45°C

ISM 2.4G

2402---2480MHz

0dbm

Approx. 161g

IMMORTAL WIRELESS CONTROLLER

USER MANUAL

FEATURES

Reset hole

• Compatible with PS3™

• Wireless Bluetooth®

• Built-in dual motors

• Soft-touch rubber ﬁnish

• Up to 10 meters range wireless connection

• Non-slip & ergonomic precision triggers

• Battery Capacity: 600mAh

• 1.2m charging cable

Square

Triangle

10D-pad

Right analog

joystick/R3

Home button

Left analog

joystick/L3

Start

Cross

Circle

Select

Product specificaties

Merk:	Dragonshock
Categorie:	Controller
Model:	Immortal
Kleur van het product:	Black, Blue
Gewicht verpakking:	161 g
Breedte verpakking:	175 mm
Diepte verpakking:	80 mm
Hoogte verpakking:	175 mm
Stroombron:	Batterij/Accu
Capaciteit van de accu/batterij:	600 mAh
Type verpakking:	Hangende doos
Connectiviteitstechnologie:	Draadloos
Non-slip surface:	Ja
Ergonomische grip:	Ja
Aansluitbereik:	10 m
Soort apparaat:	Gamepad
Aansluiting:	Bluetooth
Rubberen handgrepen:	Ja
Oplaadbare batterij:	Ja
Gaming controle technologie:	Analoog
Analoge duim-sticks:	Ja
Gaming platforms ondersteund:	Playstation 3
Gaming controle functie toetsen:	D-pad, Home button, Select button, Start button
