Contents
Refer to the numbered drawings that go with the numbered paragraphs in the instructions
Introduction 1
Installation 1
Use and Safety 3
Cleaning and hygiene 5
Fault nding 6
Maintenance 6
Compliance with regulations 8
Introduction
1.1 DESCRIPTION
• These electronic beater-mixers are professional bakery and
pastry-making appliances designed for kneading, mixing and
whisking all kinds of food products. The A version appliances
are suitable for kitchens and can be used to drive accessory
appliances.
A Stainless steel bowl, 20 or 30 litre capacity
(depending on model)
B Removable safety guard and with additional plastic screen
C Type H accessories socket
D Head
E Control panel
G Lift/lower lever
H Planetary gear system
I Column
J Bowl cradle
K Feet
• 3 tools are available as standard supply:
A Hook for kneading.
B Paddle for mixing.
C Whisk for emulsions
• Optional equipment:
- 20 and 30 L reinforced whisk for heavy work.
- Reduction bowl 10 L with 3 tools (20 L model)
- Reduction bowl 10/20 L with 3 tools (30 L model)
- Stainless steel table (height 480mm) for 20l table model.
• Optional equipment for versions with accessory socket A only:
- Accessory appliances (see § 3-6)
- Plate-holders for collection of products underneath the mincer,
vegetable preparation attachment, sieve.
Installation
XBE20/30 GB 10 20231
1.1b
GB
10/2023
Introduction
The User Manual contains useful information for the user on how
to work correctly and in complete safety, and is designed to make it
easier to use the machine (called “machine” or “appliance” below).
What follows is in no case intended to be a long list of warnings
and constraints, but rather as a series of instructions meant to
improve the service provided by the machine in every respect,
and particularly to avoid a series of injuries or damage to equip-
ment that might result from inappropriate procedures for use
and management.
It is essential that all the people responsible for transporting,
installing, commissioning, using, maintaining, repairing or dis-
mantling the machine should consult this manual and read it
carefully before proceeding with the various operations, in order
to avoid any incorrect or inappropriate handling that might be
result in damage to the machine or put people’s safety at risk.
It is just as important that the Manual should always be available
to the operator and it should be kept carefully where the machine
is used ready for easy and immediate consultation in case of any
doubt, or in any case, whenever the need arises.
If after reading the Manual, there are still any doubts concerning
how to use the machine, please do not hesitate to contact the
Manufacturer or approved After Sales Service provider, who is
constantly available to ensure quick and careful service for improved
machine operation and optimum eciency.
Note that the safety, hygiene and environmental protection stan-
dards currently applicable in the country where the machine is
installed must always be applied during all phases of machine
operation. Consequently it is the user’s responsibility to ensure
that the machine is operated and used solely under the optimum
safety conditions laid down for people, animals and property.
ATTENTION!!
Machine storage: -25°C to +50°C
Ambient temperature during operation: +4°C to +40°C
This machine is for professional use and must be used by sta trained to use, clean and maintain it, in terms or reliability and safety.
Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard
EN 12464-1)
When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the
lower limbs.
The machine is not designed for use in explosive atmospheres.
The reference language for these instructions is French.
2.2 LOCATION
• The 20/30 litre mixers are oor-standing only.
• To chock or make the beater level:
- Remove the cap from the front foot to be adjusted.
- With a screw driver, turn the adjustable foot until it is in
contact.
- Check the machine is stable by running the mixer at high speed
with its paddle. If necessary the foot can be adjusted more
precisely with the machine running.
- Replace the cap.
• To embed the mixer in the oor: embedding the rear feet:
- Remove the caps from the 2 rear feet.
- Identify the 2 holes to be drilled (screw Ø8 max., length 80
min., plugs not supplied).
Note: It is also possible to embed the front feet, in which
case the adjustable foot is to be removed.
• The 20 litre table mixers can be installed on:
- perfectly stable, non resonant support (unit, table, etc) of height
between 350 and 500 mm.
- an optional stainless steel table with storage shelf.
• To install, proceed as follows:
- Remove the adjustable pads from the front feet.
- Line up the 4 feet xing holes on the mixer with those on the
table.
- Fix the mixer on the table using the screw set provided.
• To chock or make the table level:
- Unscrew the screws xing the pads (13 mm pipe wrench).
- Adjust the pad, then lock in position.
- Check for stability by running the mixer at high speed with its
paddle.
• To embed the table in the oor :
- Counter drill the pad xing holes (plugs and screws max ø 8,
length min 30, not supplied).
2.2a
2.2b
2.2c
2.1 DIMENSIONS - WEIGHT (for information only)
A Gross weight when packaged:
B Net weight when equipped (kg)
C Package dimensions (mm) L x w x h
D Overall dimensions of machine: L x w x H (mm)
E Dimensions for tting beater: E x E1 x E2 (mm)
Hp Height of accessory socket (A models)
Handling - Transport
- The beater is delivered xed to a wooden pallet.
- Use a forklift truck to remove it from the pallet, slipping the
forks beneath the feet.
If unloaded manually, take all necessary precautions to
ensure the appliance does not tip at all
2.3 ELECTRICAL CONNECTION
ATTENTION!!
Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised
person (see current standards and legislation in the country of installation).
If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than
those of the machine.
Do not use multiple plugs
The AC power supply to the machine must comply with the following conditions (EN60204-1);
- Maximum voltage variation: ±10%
- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods
ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard
requirements in the country where used.
- Check that the electric mains voltage, the value shown on the specication plate.
- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using a
circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and machine
specications – see the specications shown in column F of gure 2.3a
ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and
connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC
60204-1) with the use of protection devices for automatic shut-o of power in the event of an insulation fault with a TN or
TT, system, or for the IT system, with the use of a permanent insulation or dierentials controller for automatic shut-o.
The requirements of IEC 60364-4-41, 413.1 must apply for this protection.
For example: in a TN or TT system, a dierential circuit breaker must be installed upline of the power supply, with a
suitable power cut-o (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.
ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-
dents due to direct or indirect contacts.
XBE20/30 GB 10 2023 2
• The electronic beaters run on a single phase power supply.
• Provide an accessible standardized wall outlet with 2 poles +
ground, rated at 16A in accordance with IEC60309, and a cor-
responding waterproof plug to be installed on the power cord.
•
Check that the electric mains voltage, the value shown on the
specication plate.
Note:
The machine can only be used on TN (earthing to
neutral) and TT (earthed neutral) type supplies. Where
a machine has to be installed on an IT (impeding or
isolated neutral) supply, there is a solution which
consists of inserting an isolating transformer and locally
putting on the machine on TN or TT supply.
2.3a
• Electrical characteristics:
A : Machine
C : Supply voltage
D : Frequency
E : Nominal power
F : Rating of the fuse of the mains cable (Amperes)
• Check the direction of rotation
- Of the planetary gear, anti-clockwise (see arrow on head)
or the tool, clockwise : factory setting.
In the event of a problem, §5.2 to reverse the direction of rotation.
Use and Safety
• The beater will start normally when the bowl-holder cradle
assembly is in the working position,
- The safety guard is tted and down,
- The timer is set on continuous or timed operation.
- The bowl is in position on the cradle,
a)Timed operation
- Select time on by pressing buttons and E A B
- Start by pressing button D
- Stop at the end of the time set, or by pressing button C
Note:
- To change the time being counted down, press on button
C B then change using buttons A and ;
- resume cycle by pressing button . D
- The time displayed at the beginning of the cycle remains in memory
- To permanently interrupt a cycle underway, press button C twice.
b) Continuous operation
- Select ---- on by pressing and holding button E A
- Start by pressing button D
- Stop by pressing button C
c) Speed variation
- Select the speed on by pressing buttons and H F G
3.1
2.3b
3.1 OPERATION - SAFETY
• The safety of the user is guaranteed by:
- The motor halting when the safety guard is opened.
- The design of the guard that allows products to be added
perfectly safely during operation.
- The motor halting when the cradle is lowered. It will not start
again when the ON switch is pressed.
- The need to press the ON button after the machine has been
stopped («no volt release» device)
- Protection against current and power surges, drops in power
and the motor overheating.
- Compliance with the instructions given in this manual for using,
cleaning and maintaining the machine.
• Control panel
A Reduce time setting on timer
B Increase time setting on timer
C STOP button
D START button
E Timer display
F Increase speed
G Reduce speed
H Speed display
Must be earthed using the green and yellow wire.
• Warning for the installer:
This electronic whisk is tted with a lter which sends any in-
terference from the mains to earth without going through the
variator. To work properly, the appliance earth connection must
be sound otherwise the interference may go through the variator
and damage it.
NO EARTH = NO PROTECTION = RISK OF BREAKDOWN
Note: The earth values are dened according to the
residual dierential current. Non-compliance with these
instructions may result in invalidation of the warranty.
In certain circumstances depending on the sensitivity of the
protective cut-outs, it may be necessary to install SI-type
(super immunity) devices to prevent untimely triggering.
To PAT test the Electrolux Range of Food Preparation Equipment,
the PCB board needs to be disconnected before any test is done.
This is due to the fact that the boards are tted with a grounding
diode that can give incorrect result during such a test. Also on a
standard appliance a ash test of 25 amps and up to 3000v is used
but, as you would expect, to use this on equipment, which has a
printed circuit, board would be quite destructive to that board. We
would recommend the use of a PAT tester approved for computer
systems which use a lower rate of amps.
The appliance is perfectly safe and is CE certicated. There are
two ways to get overcome this problem.
· Disconnect the board as instructed and test using test for PC’s,
· Or install the mixer on a fused spur (no plug) as this takes it
away from being a portable appliance and the PAT test is then not
needed.
Clean the machine properly prior to its rst use
Uncontrolled closure of the lid or ram press involves a risk of crushing the ngers.
Never put a hand in the ejection area while the machine is in operation; risk of injury. It is strictly forbidden to put the safety systems
out of action or modify them: Risk of permanent injury!!!!
Check that the safety devices operate correctly each time before using (see paragraph on «safety system adjustments»). Never
put a hand, a hard or frozen object in the appliance
For health and safety reasons, always use a washable or disposable strong head covering that covers the hair completely.
ATTENTION!!
XBE20/30 GB 10 20233
Do not use the machine without the bowl.
Product specificaties
| Merk: | Dito Sama |
| Categorie: | Niet gecategoriseerd |
| Model: | 600167 |
Heb je hulp nodig?
Als je hulp nodig hebt met Dito Sama 600167 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Niet gecategoriseerd Dito Sama
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
Handleiding Niet gecategoriseerd
- CDVI
- Domyos
- Cyrus
- Fischer
- Rangemaster
- Singer
- B.E.G.
- Rösle
- Weston
- Belena
- Neno
- OXO Good Grips
- Pentax
- Phoenix Gold
- Novis
Nieuwste handleidingen voor Niet gecategoriseerd
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
