Pagina 1/8
Contents
Please refer to the numbered drawings which correspond to the paragraph
numbers in the instruction manual.
GB
Introduction 1
Installation 1
Use and safety 3
Cleaning and hygiene 5
Fault nding 6
Maintenance 6
Compliance with regulations 8
Introduction
1.1 DESCRIPTION
• These beater-mixers are professional bakery/pastry maker
appliances designed for kneading, mixing and whisking all food
products. The A versions when tted in the kitchen, can be used
to power accessory machines.
A Stainless steel bowl, 20/30 litre capacity
(Depending on model)
B Removable protection screen and with additional plastic
screen
C H-type accessories hub
D Head
E Control panel
F Speed change lever
G Raising and lowering lever
H Planet gear
I Column
J Bowl support cradle
K Feet
• There are 3 standard tools available :
A A spiral hook for kneading dough
B A paddle for mixing
C A whisk for emulsifying
• Optional equipment :
- Strengthened 20 L whisk for dicult work
- Reduced bowl of 10L with 3 tools (models 20l)
- Reduced bowl of 20L and 30L with 3 tools (models 30l)
- Stainless steel table (height 480mm) for 20l table model.
•Optional equipment for A accessory hub versions only:
- Accessory machines (see § 3-6).
- Plate holder to collect products under the mincer, vegetable
slicer and sieve.
Installation
XBM20/30 GB 09 20231
09/2023
1.1b
Introduction
The User Manual contains useful information for the user on how
to work correctly and in complete safety, and is designed to make it
easier to use the machine (called “machine” or “appliance” below).
What follows is in no case intended to be a long list of warnings
and constraints, but rather as a series of instructions meant to
improve the service provided by the machine in every respect,
and particularly to avoid a series of injuries or damage to equip-
ment that might result from inappropriate procedures for use
and management.
It is essential that all the people responsible for transporting,
installing, commissioning, using, maintaining, repairing or dis-
mantling the machine should consult this manual and read it
carefully before proceeding with the various operations, in order
to avoid any incorrect or inappropriate handling that might be
result in damage to the machine or put people’s safety at risk.
It is just as important that the Manual should always be available
to the operator and it should be kept carefully where the machine
is used ready for easy and immediate consultation in case of any
doubt, or in any case, whenever the need arises.
If after reading the Manual, there are still any doubts concerning
how to use the machine, please do not hesitate to contact the
Manufacturer or approved After Sales Service provider, who is
constantly available to ensure quick and careful service for im-
proved machine operation and optimum eciency.
Note that the safety, hygiene and environmental protection stan-
dards currently applicable in the country where the machine is
installed must always be applied during all phases of machine
operation. Consequently it is the user’s responsibility to ensure
that the machine is operated and used solely under the optimum
safety conditions laid down for people, animals and property.
ATTENTION!!
Machine storage: -25°C to +50°C
Ambient temperature during operation: +4°C to +40°C
This machine is for professional use and must be used by sta trained to use, clean and maintain it, in terms or reliability and safety.
Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard
EN 12464-1)
When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the
lower limbs.
The machine is not designed for use in explosive atmospheres.
The reference language for these instructions is French.
2.2 INSTALLATION
• The 20/30 litre mixers are oor-standing only.
• To chock or level the beater:
- Remove the foot end piece before adjusting.
- Screw with a screwdriver so that the adjustable pad makes
contact.
- Check it is stable by running the beater at high speed with its
beater. Where necessary, the adjustment can be ne-tuned
with the machine running.
- Ret the plug.
•
To x the beater to the oor: x by the rear feet
- Remove the end pieces from the 2 rear feet.
- Mark the 2 holes to be drilled (Ø8 max. screw, min. length 80,
plugs not supplied).
Note : It is also possible to x to the oor by the front feet,
by removing the adjustable pad.
• The 20 litre table mixers can be installed on:
- perfectly stable, non resonant support (unit, table, etc) of height
between 350 and 500 mm.
- an optional stainless steel table with storage shelf.
• To install, proceed as follows:
- Remove the adjustable pads from the front feet.
- Line up the 4 feet xing holes on the mixer with those on the
table.
- Fix the mixer on the table using the screw set provided.
• To chock or make the table level:
- Unscrew the screws xing the pads (13 mm pipe wrench).
- Adjust the pad, then lock in position.
- Check for stability by running the mixer at high speed with its
paddle.
• To embed the table in the oor :
- Counter drill the pad xing holes (plugs and screws max ø 8,
length min 30, not supplied).
2.2a
2.2c
2.2b
2.1 DIMENSIONS - WEIGHT (for information only)
A Gross weight when packaged (kg)
B Net weight equipped (kg)
C Packaging dimensions (mm) L x W x H
D Machine dimensions: L x W x H (mm)
E Dimensions for beater bedding: E x E1 x E2 (mm)
Hp Accessories hub height (A models)
. Handling - Transport
- The beater is delivered xed to a wooden pallet.
- Use a forklift truck to remove it from the pallet, slipping the
forks beneath the feet.
If unloaded manually, take all necessary precautions to
ensure the appliance does not tip at all
2.3 ELECTRICAL CONNECTION
ATTENTION!!
Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised
person (see current standards and legislation in the country of installation).
If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than
those of the machine.
Do not use multiple plugs
The AC power supply to the machine must comply with the following conditions (EN60204-1);
- Maximum voltage variation: ±10%
- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods
ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard
requirements in the country where used.
- Check that the electric mains voltage, the value shown on the specication plate.
- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) by using
fuses or thermal relays of the appropriate gauge relative to the place of installation and machine specications – see the spe-
cications shown in column F of gure 2.3a
ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and
connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1
(IEC 60204-1) with the use of protection devices for automatic shut-o of power in the event of an insulation fault with
a TN or TT, system, or for the IT system, with the use of a permanent insulation or dierentials controller for automatic
shut-o. The requirements of IEC 60364-4-41, 413.1 must apply for this protection.
For example: in a TT system, a dierential circuit breaker must be installed upline of the power supply, with a suitable
power cut-o (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.
ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-
dents due to direct or indirect contacts.
XBM20/30 GB 09 2023 2
• Motor specications:
B Number of phases (1 single phase or 3 three-phase)
C Nominal voltage in volts (value, range or commutation)
D Frequency (Hertz)
E Nominal rating (Watts)
F Rating of the fuse of the mains cable (Amperes)
1) Three-phase motor
• A standard wall socket with 3 poles + Earth, rated at 20A com-
pliant with IEC60309 will be required and a matching watertight
plug tted to the power supply cable.
• Check the direction of rotation:
- of the planet gear, anti-clockwise direction (see arrow on
head)
- of the tool, clockwise direction.
• If the direction of rotation is reversed, change over the two
phase wires on the plug.
• Connection is made at higher voltage for 400V). For
connections to lower voltage supplies 230V proceed as
follows:
- Unplug the machine.
- Remove the rear plate.
- Refer to the wiring diagram in § 6.6.
This appliance must be earthed with a green/yellow wire.
- Change over the integral plate wire by moving the cable lug
from the terminal marked for the higher voltage (400V) onto
that for the lower voltage (230V).
- Change over the plate straps on the terminal plate.
- Check the direction of rotation and ret the plate.
2) Single phase motor
• A standard single phase wall socket with 2 poles + earth, rated
at 10/16 A will be required.
• The direction of rotation is factory-set.
2.3a
2.3b
2.3c
Use and Safety
3.1 OPERATION - SAFETY
• The user’s safety is ensured by:
- The motor stopping on opening the protection screen.
- The design of the screen which allows products to be added
while working in complete safety.
- The motor stopping on lowering the cradle. It will not start again
by pressing the START button.
- The START button needing to be pressed after a stoppage
(“voltage loss” device).
- The motor being protected against overload by a thermal sensor.
- Following the instructions in this manual for using, cleaning
and maintaining the machine.
• Control panel
A Reduce time setting on timer
B Increase time setting on timer
C STOP button
D START button
E Timer display
• The beaters are normally started if the bowl support cradle
assembly is in the working position.
- The protection screen is tted and closed.
- The timer is set to continuous or timed operating mode.
- The bowl is in position on the cradle.
a) Timed operation
- Select time on by pressing buttons and E A B
- Start by pressing button D
- Stop at the end of the time set, or by pressing button .C
Note:
- To change the time being counted down, press on
button then change using buttons and C A B;
resume cycle by pressing button . D
- The time displayed at the beginning of the cycle remains in
memory
- To permanently interrupt a cycle underway, press button twice.C
b) Continuous operation
- Select --- on by pressing and holding button E A
- Start by pressing button D
- Stop by pressing button C
3.1
To PAT test the Electrolux Range of Food Preparation Equipment,
the PCB board needs to be disconnected before any test is done.
This is due to the fact that the boards are tted with a grounding
diode that can give incorrect result during such a test. Also on a
standard appliance a ash test of 25 amps and up to 3000v is
used but, as you would expect, to use this on equipment, which
has a printed circuit, board would be quite destructive to that
board. We would recommend the use of a PAT tester approved
for computer systems which use a lower rate of amps.
The appliance is perfectly safe and is CE certicated. There are
two ways to get overcome this problem.
· Disconnect the board as instructed and test using test for PC’s,
· Or install the mixer on a fused spur (no plug) as this takes it
away from being a portable appliance and the PAT test is then
not needed.
ATTENTION!!
Clean the machine properly prior to its rst use
Uncontrolled closure of the lid or ram press involves a risk of crushing the ngers.
Never put a hand in the work area while the machine is in operation; risk of injury. It is strictly forbidden
to put the safety systems out of action or modify them: Risk of permanent injury!!!!
Check that the safety devices operate correctly each time before using (see paragraph on «safety system checks»).
Never put a hand, a hard or frozen object in the appliance
For health and safety reasons, always use a strong washable or disposable head covering that covers the hair completely.
XBM20/30 GB 09 20233
Do not use the machine without the bowl.
Product specificaties
| Merk: | Dito Sama |
| Categorie: | Niet gecategoriseerd |
| Model: | 600165 |
Heb je hulp nodig?
Als je hulp nodig hebt met Dito Sama 600165 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Niet gecategoriseerd Dito Sama
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
Handleiding Niet gecategoriseerd
- Yorkville
- WAYDOO
- Biostar
- OneConcept
- Icy Dock
- Erica Synths
- Sure-Fi
- DPA
- Svan
- Weston
- Futaba
- Invacare
- Casaria
- INIU
- Puky
Nieuwste handleidingen voor Niet gecategoriseerd
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
