Pagina 1/6
• Standard all stainless steel equipment :
X Hook for kneading dough.
Y Paddle for mixing.
Z Whisk for emulsifying
1.1 DESCRIPTION
• This electronic beater-mixer is a small appliance for bakery-pa-
tisserie and cooking designed for kneading, mixing and whipping
all kinds of food products all kinds of pastry ,stulling ,cream
,emulsions ,etc. The power take-o drives accessories (with
conical push-t and square shaft of 12, type K). It is lightweight
and compact and easy to handle.
2.2 LOCATION
This beater mixer is designed to be tted on a stable, non-vibrating
worktop between 600 and 900 mm in height.
2.1 DIMENSIONS – WEIGHT (FOR INFORMATION ONLY)
A Stainless steel bowl, 5.5 litre capacity
B Bowl cradle
C Safety guard
D Built-in accessories hub
E Cover
Introduction
Installation
- Gross weight packaged : 15 Kg
- Net weight with equipment : 12.6 Kg with tools
- Dimensions of packaging : 450 x 350 x 490 mm
- Machine overall dimensions : 388 x 280 x 438 mm
1.1b
Refer to the numbered drawings
that go with the numbered paragraphs in the instructions.
Introduction 1
Installation 1
Use, safety 2
Cleaning and hygiene 4
Fault nding 5
Maintenance 5
Conformity with regulations 6
Contents
GB
1
Electromix 5 GB 11 2023
2.1
1.1a
F Head
G On/O/Speed variation button
H Base
Introduction
The Operating Manual provides the user with useful information
in order to work correctly and in complete safety. It is designed to
facilitate use of the machine (hereinafter referred to as “machine”
or “appliance”).
The following should not under any circumstances be considered
as a long list of restrictive warnings, but rather as a set of instruc-
tions aimed at improving the performance of the machine in all
respects and particularly at preventing bodily injury or material
damage resulting from improper use and management.
It is essential that all the people responsible for transporting,
installing, commissioning, using, maintaining, repairing or dismant-
ling the machine should consult this manual and read it carefully
before proceeding with the various operations, in order to avoid
any incorrect or inappropriate handling likely to result in damage
to the machine or putting people’s safety at risk.
It is also important for the Manual to be ever available to the
operator and carefully kept at the workplace of the machine in
order to be easily and immediately consulted in the event of a
doubt or, in any case, as required.
If, after reading this Manual, you still have doubts or uncertainties
as to the use of the machine, please do not hesitate to contact
the Manufacturer or approved After-Sales Service who remain at
your disposal in order to guarantee a quick and thorough service
with a view to optimum operation and eciency of your machine.
As a reminder, the safety, hygiene and environmental protection
standards currently applicable in the country where the machine
is installed must always be applied during use of the machine.
Consequently, it is the user’s responsibility to ensure that the
machine is operated and used solely under the optimum safety
conditions laid down for people, animals and property.
The machine can be transported holding it either side of the cradle
with the guard shut. Do not use the control button as a handle.
11/2023
Use the machine in a sufficiently lit room (see technical
standard currently applicable in the country of use, for
Europe, refer to standard EN 12464-1)
THE REFERENCE LANGUAGE FOR THESE INSTRUCTIONS IS FRENCH.
2.3 ELECTRICAL CONNECTION
ATTENTION!!
Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised
person (see current standards and legislation in the country of installation).
If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than
those of the machine.
Do not use multiple plugs
The AC power supply to the machine must comply with the following conditions (EN60204-1);
- Maximum voltage variation: ±10%
- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods
ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard
requirements in the country where used.
- Check that the electric mains voltage, the value shown on the specication plate.
- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using a
circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and machine
specications –
ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and
connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC
60204-1) with the use of protection devices for automatic shut-o of power in the event of an insulation fault with a TN or
TT, system, or for the IT system, with the use of a permanent insulation or dierentials controller for automatic shut-o.
The requirements of IEC 60364-4-41, 413.1 must apply for this protection.
For example: in a TN or TT system, a dierential circuit breaker must be installed upline of the power supply, with a
suitable power cut-o (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.
ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-
dents due to direct or indirect contacts.
•
Electrical specications of machine:
• This beater is to be supplied with single-phase current.
• Provide an accessible standardized wall outlet with 2 poles +
ground, rated at 16A in accordance with IEC60309, and a cor-
responding waterproof plug to be installed on the power cord.
NO EARTH PLUG = NO PROTECTION = RISK OF
BREAKDOWN.
Voltage Rating Frequency Current
(V) (W) (Hz) (A)
220/240 500 50/60 2,3
The machine must be earthed using the green and yellow wire
Note: The earth values are dened according to the
residual dierential current. Non-compliance with these
instructions may result in invalidation of the warranty.
3.1 OPERATION - SAFETY
Use, safety
Read all the instructions.
- The appliance must be used by professional personnel.
- Do not put machine in water or any other liquid to avoid any
risk of electric discharge.
- Disconnect the plug of the appliance when not in use or before
any maintenance operation or cleaning.
- Check that the appliance is in position 0 when:
- it is not in use
- before attaching or removing tools, accessories
- before cleaning.
- Remove accessories and tools from beater before washing
- Never touch moving parts.
- Keep hands, hair, clothing, spatulas and other utensils away
from the tools when in operation to reduce any risk of injury
and/or damaging the appliance.
- Do not use the machine if:
- the cable or plug is damaged
- the safety component (guard) is faulty.
- the appliance has fallen or shows signs of damage.
Electromix 5 GB 11 2023
2
Do not lift the safety guard up until the mixer has stopped
completely to prevent splashes.
3.1
3.2 LOADING INGREDIENTS INTO THE BOWL
It is easier to put the ingredients into the bowl before putting
it on to the appliance. This is strongly recommended for our
(when preparing various dough mixtures). To avoid a cloud of
our from forming when loading the bowl, you are advised to:
- Empty the bag or container of our without shaking it.
- Put the water in before the our if possible.
- Do not shake the contents once the our has gone into the
bowl.
- Place the tool gently into the bowl before placing it on to the
appliance.
These simple precautions will limit a cloud of our from for-
ming and consequently, reduce the risk of dust-related aller-
gies.
However, some mixtures call for products to be added during
the process. This is made easier thanks to the funnel guard
which channels any products added after. Avoid adding pro-
ducts by dropping them onto the tool to prevent splashing re-
lated to the rotation speed of the tool.
Do not add frozen products, ice cubes or any other hard mat-
ter such as sugar cubes or chocolate for instance which risks
blocking the appliance or at the worst, damaging the bowl and
tools.
Always adhere to the maximum recommended quantities to
avoid overows and splashing when working.
• The working capacity of a beater depends upon:
- the tool used
- the nature, quantity and density of the mass to be worked
- the optimum speed for quality results.
• Too large a quantity is always detrimental to the quality of
the work and the life of the mechanical parts of the beater
and may lead to abrupt stoppage (See § 5.1).
•
The table opposite gives an indication of the maximum quantities
to be used for quality work.
Caution: incorrect speed (too fast) may aect the
machine’s balance.
Always monitor the machine when it is running
When moving the machine:
- 1 reduce speed.
- 2 check that the machine’s feet and the work surface
are clean.
3.3 MAXIMUM CAPACITIES
WHISK PADDLE HOOK
Meringue: Crème pâtissière: Croissant:
350g egg whites 500g of powder mix 750g of our
Genoese sponge: Choux pastry: Brioche:
400g egg whites 600g of our 750g of our
Sti egg white: Shortcrust pastry: Choux pastry:
400g egg whites 500g of our 600g of our
Whipped cream: Sweet pastry: Sweet pastry:
1L of single cream 500g of our 750g of our
Chocolate mousse: Bread dough 60%
500g of powder mix 750g of our
Pancake batter Pizza
1.5L of milk 400g of our
1 kg of lling
1 kg of sausage
meat
1 kg of pâté
3.3
- The use of accessories not recommended or not sold by the
manufacturer could lead to re, electrical discharge or injury.
- Do not use the appliance outdoors.
- Do not allow the cable to hang over the edge of the table or a
worktop.
- Do not allow the cable to touch a hot surface, including an
oven.
- Never operate the appliance without its safety guard.
- Never operate the appliance without its bowl.
- KEEP THESE INSTRUCTIONS
• The safety of the user is guaranteed by:
- The safety guide which stops the appliance when it is lifted.
- The machine only starting when the cradle is in the work po-
sition and the safety guard lowered the bowl is in position on
the cradle.
- A time of less than three seconds for the beater to stop regardless
of the speed.
- A no-volt release system requiring for the speed button to be
at 0 to start back up.
- Protection from current and voltage overloads and the motor
from heating.
G Rotary ON/OFF/VARIATION button
O Position 0 : OFF
I Position 1 to 12 . SPEED ADJUSTMENT
a) Electronic speed variation
- Turn the variation button:
Clockwise to increase speed.
Anticlockwise to reduce speed.
Note: Do not force the min. - max. stops of the button,
as this may damage the potentiometer.
b) Braked stop
- By bringing the variation button back to 0.
• Raise the safety guard and the cradle will be lowered automa-
tically.
• Place the tool inside the bowl.
• Position the bowl in front of the cradle and engage the handles
of the bowl in the pins of the cradle.
• Push the tool into the tool holder spindle, then turn it anticlockwise
to lock it in position.
• Push the safety guard back and the bowl will be automatically
locked into position.
Note: If the bowl is not tted correctly, it will not be
possible to close the safety guard completely. Do not
force and ensure the bowl is correctly tted.
3.4 FITTING THE BOWL AND TOOLS
3.4c
3.4b
3.4a
§5.3
3
Electromix 5 GB 11 2023
Product specificaties
| Merk: | Dito Sama |
| Categorie: | Niet gecategoriseerd |
| Model: | 600136 |
Heb je hulp nodig?
Als je hulp nodig hebt met Dito Sama 600136 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Niet gecategoriseerd Dito Sama
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
Handleiding Niet gecategoriseerd
- Staudte-Hirsch
- Lifan
- Ansco
- Pelco
- Primo
- Icron
- Boehringer Ingelheim
- Bush
- Euromaid
- Kryptonite
- GoDEX
- Ferroli
- Adam
- Chord
- Clean Paper
Nieuwste handleidingen voor Niet gecategoriseerd
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
