Pagina 1/2

Assembly Drawing

COUGAR Facebook

PANZER

T H E U L T I M A T E C O M P U T E R C A S E

MOTHERBOARD

●

Four different motherboard form factors: Mini ITX / Micro ATX / ATX / CEB

GRAPHICS

●

7 expansion slots

●

Up to 3 graphics cards

●

Graphics card length up to 425 mm (400mm with frontal fans)

●

VR and 4K ready

STORAGE

●

Up to Six 2.5" SSD or four 2.5" SSD and two 3.5" HDD

PLENTY OF COOLING

●

Up to four radiators (front or top maximum radiator length up to 360mm)

●

Up to eight 120mm fans

●

Pro-cooling mesh design

SUPERB DESIGN

●

Metallic Design of Military Inspiration

●

Cover for the PSU that keeps your build aesthetics clean

●

Tempered Glass Right/Left Cover for Full Internal View

●

Estructura de vidrio templado en los lados izquierdo y derecho para una

visión total.

●

Cobertura para la fuente que mantiene un diseño y estética clean.

●

Refrigeración abundante:

●

Hasta cuatro radiadores

(tamaño máximo de los radiadores adelante o arriba: 360mm)

●

Hasta ocho ventiladores de 120mm

●

Mucho espacio, muchas opciones:

●

Soporta cuatro formatos diferentes de motherboard

(Mini ITX / Micro ATX / ATX / CEB).

●

Hasta tres placas gráficas de 425mm

(400mm con ventiladores frontales).

●

Listo para VR e 4K.

●

Seitenflächen rechts/links aus Tempered Glass für direkten Blick auf die Hardware

●

Netzteil-Abdeckung für aufgeräumte Optik im Inneren

●

Großzügige Kühlmglichkeiten

●

Einbaumöglichkeit für bis zu vier Radiatoren

(Radiatoren von bis zu 360 mm Länge an der Vorder- oder Oberseite)

●

Platz für bis zu acht 120-mm-Lüfter

●

Viel Platz, alle Optionen

●

Unterstützung für vier Mainboard-Standards (Mini-ITX, Micro-ATX, ATX, CEB)

●

Einbaumöglichkeit für bis zu drei Grafikkarten mit 425 mm Länge

(max. 400 mm falls Lüfter an der Vorderseite verbaut werden)

●

Ideale Basis für VR- und 4K-Gaming-Systeme

●

Vetro temperato da entrambi i lati del case per una vista interna completa.

●

Copertura per l'alimentatore per un design pulito.

●

Cooling di alte performance

●

Fino a quattro radiatori frontali da 360mm

●

Fino a otto ventole da 120mm

●

Tanto spazio, tante scelte.

●

Compatibile con quattro differenti schede madri

(Mini ITX, Micro ATX, ATX, CEB)

●

Fino a 4 schede grafiche da 425mm

(400mm se le ventole frontali sono installate)

●

Compatibile con VR e 4K

●

Estrutura de vidro temperado nas laterais esquerda e direita para uma

visão completa.

●

Cobertura para a fonte que mantém um design e estética clean.

●

Refrigeração Abundante:

●

Até quatro radiadores

(tamanho máximo dos radiadores na frente ou no topo: 360mm)

●

Até oito ventiladores de 120mm

●

Muito espaço, muitas opções:

●

Suporta quatro formatos diferentes de placa mãe

(Mini ITX / Micro ATX / ATX / CEB)

●

Até três placas de vídeo de 425mm

(400mm com ventiladores frontais).

●

Com entradas de VR e 4K

PORTUGUÊS

ESPAÑOL

DEUTSCH ITALIANOENGLISH

Power button

Reset button

USB 3.0 / USB 2.0

/ HD audio ports

Removable front panel

Tempered glass right cover

Tool-less screw

Tempered glass left cover

Vented slot cover

Power supply cover

3.5" HDD trays

(compatible with 2.5" HDD/SSD)

2.5" HDD/SSD trays

1 x 120mm fan for bottom panel

(optional, purchased separately)

2 x 140 / 3 x 120mm fans for front panel

(optional, purchased separately)

2 x 140 / 3 x 120mm fans for front panel

(optional, purchased separately)

Top panel

1 x 120mm fan for rear panel

(pre-installed)

Slot side cover

Front fan filters to prevent dust from

getting into the chassis

440mm

1 7 . 3 2 "

4 4 5 m m

1 7 . 5 2 "

Installing a water cooler (top)

Installing a water cooler (front)

LEFT

45°

3.5" HDD

RIGHT

RIG

Installing an internal

2.5" HDD/SSD

RIGHT

LEFT

Installing a power supply

LEFT SIDE RIGHT SIDE REAR SIDE

ACCESSORY KIT

X 8Power supply screws

X 24Fans screws

X 24SSD screws

Motherboard / HDD screws X 17

X 4

X 1

Cable ties

Psu bracket

PSU BRACKET

X 2Stand-off

Compucase Enterprise Co.,Ltd.

No. 225, Lane 54, An Ho Road Sec.

2 Tainan, Taiwan, R.O.C

Tel:+886-6-356-0606

Service E-Mail: service@cougargaming.com

For more information, please visit www.cougargaming.com

Compucase Enterprise Co.,Ltd.

www .c ou gargaming.com

Made in China

facebook.com/cougargaming

youtube.com/user/COUGARGLOBAL

1 2 3

REAR

Product specificaties

Merk:	Cougar
Categorie:	Computerbehuizing
Model:	Panzer
Kleur van het product:	Zwart
Breedte:	208 mm
Diepte:	520 mm
Hoogte:	565 mm
Soort:	PC
Vormfactor:	Midi Tower
Aan-/uitknop:	Ja
Aantal USB 2.0-poorten:	2
Geschikt voor:	Gamen
Audio-ingangen:	Ja
Audio-uitgang:	Ja
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	2
Vermogenstoevoer inclusief:	Nee
Aantal 2.5" bays:	6
Aantal 3.5" bays:	2
Ondersteunde HDD-groottes:	2.5, 3.5 "
Aantal uitbreidingssleuven:	7
Verbeterd kabelbeheer:	Ja
Supported motherboard form factors:	ATX, CEB, Micro ATX, Mini-ITX
Zijraam:	Ja
Geharde glaspla(a)t(en):	Ja
Maximum CPU cooler hoogte:	160 mm
Maximum grafische kaart lengte:	425 mm
Maximale aantal ventilators voorkant:	3
Voorste ventilators ondersteunende diameters:	120,140 mm
Maximaal aantal ventilators bovenkant:	3
Bovenste ventilators ondersteunende diameters:	120,140 mm
Maximaal aantal ventilators achterkant:	1
Geïnstalleerde ventilators achterkant:	1x 120 mm
Ondersteunde vormfactoren stroomvoorziening:	ATX, PS2
Maximaal aantal ventilators onderkant:	1
Ondersterste ventilators ondersteunende diameters:	120 mm
Aantal interne 3.5" baaien:	2
HDD/SSD-combimodel:	Ja
