Ver. 20170201

LED Downlight

Art.no 36-5858 Model CED806

36-5876 CED806

36-6295 WCVC012W10

Please read theentire instruction manual before using theproduct

and save it for future reference. We reserve theright for any

errors in text or images and any necessary changes made to

technical data. If you have any questions regarding technical

problems please contact our Customer Services.

Safety

• Theproduct is intended for indoor use only (IP44).

• Installation and maintenance may only be carried out by

aqualified tradesman according to local safety regulations.

• Thelight fitting must not be used if any part is damaged.

It should either be discarded or repaired by aqualified

technician.

• None of theproduct’s parts are to be disassembled or

modified.

3. Unscrew theterminal block cover.

4. Hold down thecable holder on theterminal block and

insert theends of thewires. Pull gently on thepower

lead to make sure that thewires are firmly secured in

theterminal block.

5. Screw theterminal block cover back on. Thecover also

functions as astrain relief.

6. Lift thespring clips up and mount thelight in a76 mm hole.

Responsible disposal

• Do not cover thedownlight with

anything that will hinder ventilation such

as foil, paper or plastic.

• Make sure that thewires do not rub against sharp corners

or edges.

• Therating label containing thetype designation must not

be removed or made illegible.

• Theproduct must only be connected to a230 V AC

power supply.

Installation/mounting

Mounts in a76 mm diameter hole. Mounting depth: 90 mm.

Plan thelayout of thepower lead before you begin installation.

No minimum clearance from combustible surfaces is required

for LED bulbs.

1. Turn off thepower.

2. Strip theends of thewires as shown in thediagram.

Dimmable

Thedownlight can be used with atraditional

incandescent or LED bulb dimmer.

This symbol indicates that this product should not

be disposed of with general household waste.

This applies throughout theentire EU. In order to

prevent any harm to theenvironment or health

hazards caused by incorrect waste disposal,

theproduct must be handed in for recycling so that

thematerial can be disposed of in aresponsible

manner. When recycling your product, take it to

your local collection facility or contact theplace

of purchase. They will ensure that theproduct is

disposed of in anenvironmentally sound manner.

Specifications

Power supply200–240 V AC, 50 Hz

Power11 W (36-6295: 10 W)

Protection classIP44

Light sourceWarm white LEDs (2,300–2,700 K), 540 lm

Beam angle36°

SizeMounting hole diam: 76 mm

Outer ring diam: 90 mm

Mounting depth: 90 mm

GREAT BRITAIN • CUSTOMER SERVICEtel. 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk

postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
