8
s
8
s
WARNING!!!
(Risk of death; Prevention of accidents)
•
Do not look directly at the light source. In addition, when mounting
the light unit, ensure that the light would not dazzle other road users.
• To prevent accidents and to ensure safe riding, make sure the
light is securely attached to the bracket and it is functioning
properly without being unobstructed before the ride.
• Always pay attention to the remaining battery power by
checking the indicator periodically while using the light.
•
Do not disassemble or modify the light or any of the included items.
CAUTION!
(Prevention of injury, damage, or property damage)
• Be sure to tighten the dial by hand. When you tighten it too
hard with a tool, the screw thread may be stripped.
• Check the dial and screw on the bracket periodically, and use
them without any loosening.
• Operating the light while riding is dangerous. Always ride safely.
• Do not use high mode on public roads.
• Note that the light becomes hot while illuminated. Do not
block the lens or cover the light.
• Keep device out of the reach of children.
•
When used with a cyclocomputer, attach the headlight as far away
from the cyclocomputer as possible, as it may affect measurement.
• This device is rated IPX4 based on IEC 60529. Do not immerse
the device in water. Doing so may cause a malfunction. Wipe off
any moisture after using the device in rainy weather.
• Do not subject the light to strong vibrations, impacts, or
excessive force. Discontinue use if any abnormality occurs.
• Do not charge or use the battery at any voltage or polarity
other than that specified. Do not short-circuit the battery.
• Do not drop the light into a fire or heat the light.
• Due to the variability of LEDs, the color and brightness may
differ even between devices with the same model number.
•
Carrying a spare headlight is recommended in case the battery runs out.
• If the light unit or parts become dirty with mud, etc., clean
with a soft cloth moistened with mild soap. Never apply paint
thinner, benzine or alcohol; damage will result.
LITHIUM-ION BATTERIES
Recharge the battery for first time use or after long period of storage :
The voltage of the battery may drop due to self-discharge
during long period of storage.
• Always fully charge the battery before use.
• If the device will not be used for a long period of time, store
it in a location that is not too hot or too humid.
• Charge the battery for about 30 minutes every 6 months.
Cautions for charging and usage :
•
Charging, discharging, and storing in high temperatures will cause
the rechargeable battery to deteriorate faster. Do not place the light
inside a vehicle or near a heater. Make sure to charge only when the
ambient temperature is between 5 and 40°C.
• Please be sure that no dust or other foreign objects are
attached to the plug of the USB cable before charging.
• Do not apply a load to the connector port by hanging the
light unit during charging.
• Do not subject the light to vibrations while charging.
• Once charging is completed, be sure to disconnect the USB
cable from the charging port.
• After charging is complete, securely attach the charging port
cover to ensure waterproofing before riding.
• Charging and lighting times are approximate values, and will
vary by environmental and user conditions.
•
If the illumination time is significantly reduced even after proper
charging, the rechargeable battery may be nearing the end of its
service life.
Cautions for dispose :
When disposing the light unit, please do so in accordance with
your local regulations.
*
Please prepare a USB cable (Type-C) that can be used for charging (sold separately)
before using this product.
*
Use a 2 A or higher USB battery charger. The unit may not charge properly if less than 2 A.
* To ensure safety, do not charge the battery if the light unit is hot.
Before using the product, refer to the “LITHIUM-ION BATTERIES” section
and charge the battery.
Approx.
Constant red
light
Off
Charging
Charging is
completed
Charging time
4h
(
2A
)
The USB cable is not included in the
package because CATEYE is
committed to making environmentally
friendly and resource-saving products.
CATEYE will continue to contribute to society by creating
new values in “Safety,” “Health,” and “Environment”.
CATEYE supports the Sustainable Development Goals
movement proposed by the United Nations.
ECO FRIE NDLY
( www.cateye.com/intl/company/sdgs/ )
Design Pat. Pending
Copyright© 2025 CATEYE Co., Ltd.
HLEL1300RC-250501
1
Before using the product, be sure to read this manual thoroughly and keep it
available for future reference. If a child uses it, the child’s guardian must
read the manual and explain the precautions for use to the child. This
product is developed assuming use by bicycle. Do not use the product in any
way other than as described in this manual.
RECHARGEABLE HEADLIGHT
MODEL : HL-EL1300RC
Light unit Bracket
(
H-34N :
FlexTight™
)
Switch (Indicator)
Dial
Be sure to release Lock mode before use.
This device is equipped with a lock mode to prevent accidental operation. Lock mode is
enabled by default. To release Lock mode, press and hold the switch for about 8 seconds.
Press and hold
Press and hold
*2
*4
*4
*1
*3
*3
Double-click
Double-click
Click
Click
FlashingFlashing
Daytime
HyperConstant
Daytime
HyperConstant
HighHigh
HighHigh
MiddleMiddleLowLow
OFF
LOCK
MODE
LOCK
MODE
ON
Remaining
battery power
Approx.
50% or more
Constant blue
light
Approx.
50 - 20%
Constant
orange light
Less than
Approx. 20%
Constant red
light
If the indicator turns red, charge the product as soon as possible.
If the indicator
lights up red when
the switch is
clicked, Lock mode
is enabled.
*3
When turning the light on, it lights up in the mode that was used last time. (Mode memory function)
*2
While enabling Lock mode, the indicator will flash red and the light will flash temporarily. After the light
stops flashing, Lock mode will be enabled.
*1
The indicator will flash after lighting up red when Lock mode is released. After the indicator stops flashing
and Lock mode is disabled, Low mode will be enabled.
*4
A protection circuit will be activated if the light unit becomes too hot, and the brightness of the light will be reduced.
This is not a malfunction. The light will return to the original brightness when the temperature cools to a safe level.
Press and hold
How to mount to a bicycle
Dial
(
Vertical adjustment
)
Screw
(
Horizontal adjustment
)
To adjust the angle, loosen the dial
or the screw to the point that the
bracket moves slightly, make the
adjustment, and then tighten the
screw to fix the light unit in place.
Insert the
product until it
clicks into place.
Mounting
Press the release
tab toward the
light unit and pull
to remove.
Removing
Φ 22-35 mm
Better
When mounting the light
unit, ensure that the light
would not dazzle other
road users.
When mounting the light
unit, ensure that the light
would not dazzle other
road users.
1
2
Standard accessories
Use only genuine components to prevent accidents and malfunctions.
Optional accessories
Bracket Spacer
(
H-37AL
)
5340910
USB cable
(
Type-A
↔
Type-C
)
5342550
Bracket
(
H-34N
:
FlexTight™
)
5338827N
Bracket
(
Helmet mount
)
5341831N
Bracket
(
CFB-100
:
Center fork
)
5342440
Bracket
(
OF-200
:
Out-front 2)
1604110
Light source LED x 1
Battery type Li-ion 3.6 V 5000 mAh
Charge terminal USB Type-C
Operating time
*5
High
：
Approx. 2 hours
Middle
：
Approx. 3.5 hours
Low
：
Approx. 7.5 hours
Daytime HyperConstant
：
Approx. 6.5 hours
Flashing
：
Approx. 50 hours
Charging time Approx. 4 hours (2 A)
Charge voltage 5 V
Temperature range
Charging : 41°F – 104°F (5°C – 40°C) Operating : 14˚F – 104˚F (-10˚C – 40˚C)
Waterproof IPX4
Recharge / discharge number of times
About 300 times (until the rated capacity drops to 70%)
Dimensions / Weight
1-22/32” x 4-39/64” x 1-37/64” (43.5 x 117 x 40 mm) / 7.35 oz (208.5 g)
*5
：
Approximate average runtime at 68°F (20°C).
* The specifications and design are subject to change without notice.
2-year Warranty: Light unit only (excludes battery deterioration)
CatEye products are warranted to be free of defects from materials and workmanship for a
period of 2 years from original purchase. If the product fails to work during normal use, CatEye
will repair or replace the defect at no charge. Service must be performed by CatEye or an
authorized retailer. To return the product, pack it carefully and enclose the warranty certificate
(proof of purchase) with instruction for repair. Please write or type your name and address
clearly on the warranty certificate. Insurance, handling and transportation charges to CatEye
shall be borne by person desiring service. For UK and REPUBLIC OF IRELAND consumers,
please return to the place of purchase. This does not affect your statutory rights.
SPECIFICATIONS LIMITED WARRANTY
2-8-25, KUWAZU, HIGASHI SUMIYOSHI-KU, OSAKA, JAPAN 546-0041
For inquiries, please visit https://cateye.com/intl/contact/
CO.,LTD.
[For US Customers]
CATEYE AMERICA, INC.
Please visit https://www.cateyeamerica.com/contact-us/
Toll Free : 800.5.CATEYE
