REFERENCE QTY. REMARKS Project

Location

Architect

Engineer

Contractor

Submitted by Date

Broan-NuTone LLC, 926 West State Street, Hartford, Wisconsin, USA 53027 Broan-NuTone.com 800-558-1711

SPECIFICATION SHEET

32B 1111808A

MODEL LP510RS

LO PROFILE

VENTILATION FAN

TYPICAL SPECIFICATION

• The fan incorporates a humidity control that uses a

sophisticated humidity sensor that responds to humidity

levels that exceed the users desired set point.

• Humidity sensor allows to adjust the humidity levels between

30%-80%.

• When humidity exceeds the desired users set point, the

fan will elevate to high speed operation.

• The humidity sensor conserves energy by allowing the fan

to operate only when required.

• Fan shall have corrosion resistant galvanized steel housing.

It shall be ducted to a roof or wall cap using 4” round

ductwork.

• Blower assembly shall be removable, have a centrifugal-

type blower wheel and a DC motor designed for continuous

operation.

• Plastic damper/duct connector shall be included.

• Multi-speed 50/80/100 CFM no greater than 1.2 Sones. All

air and sound ratings shall be certified by HVI.

• Fan shall be ENERGY STAR

qualified and have an energy

efficient DC motor.

• Fan shall be cETL-us Listed for use over bathtubs and

showers when connected to a GFCI protected branch

circuit (ceiling mount only).

DESCRIPTION

BLOWER:

• Infinitely adjustable low cfm setting allows precise

adjustment to prevent over-ventilating and maximize

efficiency

• 20-min timer delay before returning to a continuous lower

speed

• DC motor for efficiency well beyond ENERGY STAR

requirement, rated for continuous operation

• Multi-speed capability ideal for meeting ASHRAE 62.2,

LEED and ENERGY STAR for homes requirements. Can

be used to comply with CA Title 24 as well as local/spot

ventilation needs

HOUSING:

• Rugged, galvanized steel construction

• Plastic, 4” oval duct connector

• Optional 4" oval to 3" round duct adaptor sold separately

(part no. S1110515)

• 3-3/8” height allows for 2” x 4” wall or ceiling installation

• Sturdy, easy, mounting directly to stud or joist

• Can be mounted in flat ceilings, sloped ceilings up to 12/12

pitch, and walls

GRILLE:

• Polymeric construction

Can be used to ventilate excess heat and humidity from single

family, residential garages.

cETL-us Listed for use over bathtubs and showers when

connected to a GFCI protected branch circuit (ceiling mount

only).

1-Year Warranty

SpecificationSSubjecttochangewithoutnotice
