AXDIS-FD3
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 11/22/24 INSTAXDIS-FD3
FORD
Bronco ...........................................................................................2021-2023
E Series .........................................................................................2021-2022
Eco Sport (w/ Harmon Kardon) ................................................ 2020-2022
Escape .........................................................................................2020-2023
F250/F350/F450/F550 (w/4.3” screen) .............................................2020
Maverick ......................................................................................2022-2023
Transit/Transit Connect ............................................................. 2020-2023
INTERFACE FEATURES
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape
• Wire cutter
• Zip-ties
TABLE OF CONTENTS
Connections ........................................................2-3
Installation .............................................................3
Programming .........................................................3
Steering wheel control (SWC) settings............4-7
LED feedback ........................................................4
Changing radio type ............................................5
Remapping SWC ..................................................6
Dual assignment instructions .............................7
Troubleshooting.....................................................8
Ford Data Interface with SWC 2020-2023
• Designed for non-amplified models*
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (Retained Accessory Power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains balance and fade
• Micro-B USB updatable
•
Retains factory backup camera on (Transit/Transit Connect Vehicles w/SYNC
®
)
* AXA2B-FD1 required to retain OEM amplifier
Note: The AXDIS-FD3 does not retain SYNC
®
.
INTERFACE COMPONENTS
• AXDIS-FD3 interface
• AXDIS-FD3 harness
• 16-pin harness
• 3.5mm adapter
APPLICATIONS
Product Info
Visit AxxessInterfaces.com for up-to-date vehicle specific applications.
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
www.MetraOnline.com
MetraOnline.com may be used
to assist with dash assembly
instructions. Simply enter your
Year, Make, Model vehicle into
the vehicle fit guide and look
for the Dash Kit Installation
Instructions.
