AXDI-FD1

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/23/20 INSTAXDI-FD1

Product Info

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Connections ............................................................2

Installation .............................................................3

Programming .........................................................3

Ford CAN Data Interface 2007-Up

APPLICATIONS

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, speed sense)

• Pre-wired AXSWC harness (AXSWC sold separately)

• Can be used in both non-amplified and amplified models

(including Sony/THX)

• Retains balance and fade (excluding Sony/THX)

• Micro-B USB updatable

Ford

Econoline (w/ CD) 2009-Up

Edge 2007-2010

Escape 2008-2012

Expedition 2007-2014

Explorer (with NAV) 2009-2010

Explorer Sport Trac (with NAV) 2009-2010

F-150 * 2009-2012

F-150 STX/FX2 base/XLT base 2013

F-150 STX/XLT base 2014

Ford (Cont)

F-250/350/450/550 2011-2012

F-250/350/450/550 XLT, XL (w/ CD) 2013-2016

F-650/750 (w/ CD) 2016-Up

Focus 2008-2011

Fusion 2010-2012

Mustang 2009-2014

Taurus 2010-2012

Lincoln

MKX 2007-2010

MKZ 2007-2009

Navigator 2007-2014

Mazda

Tribute 2008-2011

Mercury

Mariner 2008-2011

Milan 2010-2011

• AXDI-FD1 interface • AXDI-FD1 harness

• 8-pin sub/center harness

* XL models must be equipped with a CD player
